Top quality foton lovol trailer generator prices list
UK fg wilson Engine
A. More than 10-hours operation base tank
B. Deep-sea key start controller (Auto start is optional)
C. Open frame and soundproof canopy
D. Heavy duty industrial diesel engine
a. Compact size
b. Suitable for long time operation
c. Low maintenance cost
Cooling system
Combination cooling water tank fitted to meet the requirement of radiation at ambient.
Alternator (Stamford ,LeroySomer ,Engga ,Marathon )
A. Optional permanent magnet generator system provides constant excitation under all conditions.
B. Easy paralleling with mains or other generators, standard 2/3 pitch winding. To avoids excessive neutral currents.
C. Dynamically balanced rotors with sealed for life ball bearings and single construction
D. Class "H" insulation system.
E. Wide range of flanges and adapters and disc couplings.
F. Conforms to all leading industrial and marine standards.
Optional accessories
Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
A. Auto alarm system
The unit has the acoustic-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current.
B. Operation display.
a. Unit voltage, tri-phase load current and frequency display
b. Water temperature, oil pressure display
c. Fuel level, fuel temperature display
d. Audible and visual alarm lamps and buzzers
Supply standard collocation
A. Diesel engine with all accessories, 3 filters and electric systems.
B. Alternator
C. Steel structure
D. Fan and water tank cooling system
E. Flange connector
F. 12/24V starting motor and charge engine
G. Air cleaner, fuel cleaner, oil cleaner
H. On-board control panel
I. MCCB air conservation switch
J. 12/24V starting accumulator and battery line.
K. Set shock absorber
L. High-efficient silencer
Optional Equipment
1. Soundproof enclosure
2. ATS Automatic Starting Switch
3. Trailer mounting
4. 3 phase protection breakers for voltage and high currency
All-weather performance
- Good ventilation system and prevent heat radiation measures to ensure that the crew always work in the appropriate temperature.
- Muffler materials used for noise reduction greatly inhibited the mechanical noise.
- Mufflers of antenna and sound-absorbing mode, to greatly reduce the emission of exhaust noise.
- Damping efficient measures to ensure the smooth operation of diesels generators.
- 65-85 (dBA) 7 meters from gen-set.
- Containerized structure, perfect shape, lifting convenient, rainproof, anti-snow-proof, sun-proof, suitable for outdoor operation.
Note: (Rating definitions)
- Continuous Power output
- These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power. There is limitation to the annual hours of operation and these ratings can supply 10% overload for 1 hour in 12 hours.
- Standby Power Output
- These ratings are applicable for supplying continuous electrical power (at variable load) in the event an ability power failure.
- No overload is permitted on these ratings, the alternator on these ratings is peak continuous rated (as defined in ISO8528-3) at 27°c
- Model with Suffix "S"
Type of Lovol Gensets
KVA
KW
Lovol Engine Specification
Generator Dimension
(mm)
Weight
(kg)
Base tank(L)
ESP
PRP
ESP
PRP
Lovol Engine
Consump 100% Load(L/h)
Cylinder
Governor
Asp
GF3-16KW
20
25
16
20
1003G
6
4L
M
NA
1450*650*1190
754
40
GF3- 20kw
25
30
20
24
1003G
6
4L
M
NA
1450*650*1190
754
40
GF3- 24kw
33
30
26
24
1003TG
6
4L
M
NA
1450*650*1190
754
40
GF3- 30kw
42
38
33
30
1003TG
7.5
4L
M
NA
1450*650*1190
808
60
GF3- 34kw
46
42
37
34
1004G
9.5
4L
M
NA
1600*620*1250
833
80
GF3- 48kw
66
60
53
48
1004TG
13.5
4L
M
TC
1600*620*1140
867
100
GF3- 56kw
77
70
62
56
1004TG
14
4L
M
TC
1600*620*1140
982
120
GF3- 68KW
94
85
75
68
1006TG1A
17
6L
M
TC
1950*720*1190
1156
150
GF3- 80KW
110
100
88
80
1006TG2A
20
6L
M
TC
2250*1150*2050
1248
150
GF3-110kw
143
130
114
104
1006TAG
28
6L
E
TCA
2280*830*1460
1385
150
These ratings are for soundproof type with canopy.
