Specifications
150kW diesel Generator Home Power Plant1 Lowest price, super quality
2 Noise 70 db
3 CE , SGS ,TUV
4 15 months warranty
50kW - 150kW diesel Generator Home Power Plant Set
Technical Data | |||||
|
GROUP |
Manufacturer |
Saint Meilan |
|||
Model |
LS50 |
||||
Frequency |
50HZ |
||||
Power |
Standby Power |
40KW 50KVA |
|||
Prime Power |
36KW 45KVA |
||||
Open type |
Dimension(L*W*H) |
mm |
1800×750×1200 |
||
Weight |
Kg |
940 |
|||
|
DIESEL ENGINE |
Engine Manufacturer |
Lovol |
|||
Model |
1004G |
||||
Cylinder Arrangement |
4 in line |
||||
Cycle |
4 stroke |
||||
Aspiration |
Natural Aspiration |
||||
Bore×Stroke (mm×mm) |
100 x 127 |
||||
Displacement(Liter) |
3.99 |
||||
Compression Ratio |
16.5:1 |
||||
Starter Motor |
4.2kW, DC12V |
||||
Speed Stability (%) |
≤5% |
||||
Speed Governor |
Mechanical |
||||
Cooling System |
Water-cooled |
||||
Total lubrication system capacity (L) |
8.1
|
||||
Coolant capacity (without radiator) (L) |
11.2 |
||||
Fuel Consumption at 100% Load (L/h) |
11.7 (at 1500RPM) |
||||
|
Alternator |
Manufacturer |
Stamford |
|||
Model |
UCI 224D |
||||
Rated Voltage |
230/400V |
||||
Voltage regulation mode |
Auto |
||||
Exciter Type |
Brushless self exciting |
||||
Power factor |
0.8 |
||||
Capacity (Kva) |
50 |
||||
Insulation class |
H |
||||
Protection class |
IP23 |
||||
Soundproof/Silent Box:
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6. 1m<80 dB / 7m<70dB
PMC System:
1. Standard 23 pitch windings avoid excessive neutral current
2. Permanent magnet generator system provides constant excitation under all condition
3. Optional accessories available for easy paralleling with mains or other generators
4. AVR auto voltage regulation, auto exciter, auto adjustment
Accessories:
1) Standard accessories: Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, operation manual and document
2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, control system with RS232/485, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer
Control Basic
