Help CenterSmall Dynamo Generator
Related Products
Specifications
Dynamo Generator1. power from 0.65kw to 6kw
2. gasoline fuel , air-cooled
3. recoil or electric starting
4. CE,ISO9001
Small Dynamo Generator
Dynamo Generator Features:
1. Power by 4-stroke air-cooled direct injection diesel engine
2. Rated output at 4.5kW, Max. Output at 5.0kW.
3. Large fuel tank ensures hours of continuous running.
4. Brushless alternator for easy maintenance.
5. 12-volt DC output as standard configuration for battery charging and low voltage appliance.
6. Standard configuration of voltmeter enables convenient use.
7. Hydrautic-Mafnetic Circuit Breakers for overload protection and convenience
8. Sound-absorbing panels keep lower noise.
9. Wheels for easy move.
10. Full frame protection which looks more luxurious for easy
Dynamo Generator Specification:
| Gasoline Generator | ||
| Generator Model | GG950 | GG1200 |
| AC Frequency(Hz) | 50Hz | 50Hz |
| AC Con.Output (W) | 220;230;240; | 220;230;240; |
| AC Max.Output (W) | 650W | 1kW |
| Max.AC Output | 720W | 1.1kW |
| Power Factor | 1 | 1 |
| DC Output (W) | 12V/5.8A | 12V/5.8A |
| Engine | IE45 | 154F |
| Type | OHV 2-stroke; air-cooled; single-cylinder | 4-stroke; air-cooled OHV,Gasoline Engine |
| Displacement(cc) | 63 | 87 |
| Starting System | Recoil | Recoil |
| Lubrication oil | Pre-mixed Fuel(50:1) | SAE 10W/30 |
| Max.Output(hp/rpm) | 2.0/3000 | 2.4/3000 |
| Fuel Tank Capacity(l) | 4.2 | 6 |
| Continuous Work(h) | 5.8 | 6 |
| Noise Level LwA dB(A) | 90 | 90 |
| Dim(mm) | 385X315X330 | 475X372X418 |
| Gross Weight(kg) | 18.5 | 28 |
| 20ft Container Qty | 756 | 375 |
| 40ft Container Qty | overweight | 930 |
Dynamo Generator Warranty:
Guarantee for one year or 1200 running hours (accord to whichever reach first) from installed date. During the guarantee period, our company will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material, except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation. After expiration, our company provides cost spare-parts maintenance for gensets.
Dynamo Generator Delivery:
25-30days upon received your down payment.
Looking forward to your early enquiry!!!
keywords: diesel generator, small generator, 5kw diesel generator, 5kw generator, generators, diesel generators, power generator, diesel generator set
