protable generator

Specifications

protable generator
1. ISO9001 2008 ,CE ,GB/T2820,GB755 ,SONCAP Etc
2.12 month warranty
3. Good design ,low oil



Model		EP1500		EP2500		EP3500		EP4500		EP5500		EP6500		EP7500
Generator	Type	Brushless Revolving Magnetic Field ,Self-excitating , 2 poles, signle-phase
	Voltage Regulator	Condenser Type
	Frequency(HZ)	50	60	50	60	50	60	50	60	50	60	50	60	50	60
	Max. AC Output (KVA)	1.5	2	2	2.9	2.7	4.1	3.5	5	5	5.5	5.5	6	6	6.5
	Rated AC Voltage (V)	110,120,220,230,240,110/220,120/240
	Rated AC Output (KVA)	1.3	2	2	2.3	2.5	3	3	3.5	4	5	5	5.5	5.5	6
	Power Factor	cos=1
Engine	Model	SML168FA		SML168FA		SML168FB		SML177F		SML182F		SML188F-1		SML188F-2
	Type	Forced Air-cooled, 4-stroke, OHV
	Displacement (ml)	163		163		196		270		337		389		389
	Max.Output	5.5hp/4000rpm		5.5hp/4000rpm		6.5hp/4000rpm		9.0hp/4000rpm		11hp/4000rpm		13hp/4000rpm		13hp/4000rpm
	Fuel	Unleaded Gasoline
	Fuel tank Capacity(L)	11		11		11		17		17		17		17
	Continuous Operating Hours (H)	13	11	10	7.6	8	6	9.3	7.8	7	5.5	6.2	5	6.2	5
	Oil	Engine Oil SD or Higher
	Oil Capacity (L)	0.6		0.6		0.6		1.1		1.1		1.1		1.1
	Ignition system	Transistor
	Starting system	Recoil / Electric
	Operating Noise Level(7m) DB(A)	64	66	65	68	65	68	67	70	70	73	71	74	71	74



Features

1)Copper wire or aluminum wire for choose

2)Power: 0.75kw-5.5kw
3)Voltage:110 120 220 230V ,240 110/220 120/240V
4)Frequency : 50 /60HZ
5)Starting system: manual /electric start
6)with standard parts



Warranty policy

Guarantee for one year or 1200 hours whichever reach first from ex-factory date ,During the guarantee period ,Saint will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material,After expiration ,"Saint "provides cose spare pars maintenance of gensets.
