Specifications
SMLD250 200kva Deutz Generator AMF Power Plant1.BF8M
2.Low fuel consumption
3.ATS Genset
4.Deep Sea 7220
SMLD250 200kva Deutz Generator AMF Power Plant
Engine power (KW) |
120 |
|
Engine model |
TD226B-6D |
|
Engine configuration |
6-cylinder in line, 4-stroke, spontaneously inspiration, direct spray fuel system |
|
Engine cooling mode |
The Radiator suitable for 40°CTemperature, Strap drive the cooling fan with protection cover |
|
Speed control system |
Mechanical speed controller, electricity - magnet valve control switch |
|
Start mode |
24V Direct Current Start, Including alternator & battery |
|
Engine filter system |
Dry air filter type, Fuel filters, Lube filter |
|
100%load fuel consumption (L/h) |
26.4 |
29.0 |
Specific fuel consumption (g/kwh) |
≤198 |
|
Lubricating oil consumption (g/kwh) |
≤1.36 |
|
Stable frequency change rate |
≤5% |
|
Free load voltage adjusting range |
≥95%—105% |
|
Stable voltage regulator |
≤±1% |
|
Insulation class/protection grade |
Hclass/IP23 |
|
Telephone influence factor |
TIF<50/ THF<2% |
|
Accessory attached |
A suit of start battery& connective wire; Exhaust smoke siphon, Ripple absorber, Flange, Muffler; absorber on base |
|
Water tank ventilation area (mm) |
700*820 |
|
DEUTZ generator set selects BF8M series water cooled DEUTZ engine from Sino-Germany joint venture companies in China. It also includes alternator, base frame, connecting flange, fuel tank, and control system etc.
Gensets’ electric performance
Gensets compliance with all main standards, such as :GB/T2820,ISO8528,IEC34,VDE0875-N
Prime output power: 5kw-200 kw(6kva-250kva)
Rated voltage:400/230v, 440/254v, 220/127v, etc.
Phase/connecting method: 3 phase 4wire/Y type connection
Rated frequency: 50/60hz
Rated speed: 1500/1800rpm
Excited type: Brushless, self excited or PMG
Insulation: Class H
Protection: IP21~IP23
Voltage regulation: AVR automatic control
Altitude above sea level: ≤1000 meters
Ambient air temperature: ≤40°C
Relative air humidity: ≤ 90%
DEEP SEA PANEL CONTROLLER
