Specifications
1 16kw to 1600kw ,2506D-E2 one year warranty
3 CE,ISO
4 water-cooled, Soundproof, Trailer, ATS
400kw / 500kva 2506D-E Magnet Generator set
GENTSET MODEL: SML500KVA/400KW | |||||
STANDBY POWER kVA |
550 |
||||
STANDBY POWERkW |
440 |
||||
RATED POWERkVA |
500 |
||||
RATED POWERkW |
400 |
||||
POWER FACTOR |
0.8 |
||||
OUTPUT VOLTAGEV |
120/208 |
||||
MAXIMUM OUTPUT CURRENTA |
720 |
||||
ENGINE (UK original) | |||||
MODEL |
2506D-E16Tag1 |
THE MAXIMUM OUTPUT POWERkW |
483 |
||
THE NO.OF CYLINDER |
6L |
FUEL CONSUMPTION(g/kw.h) |
203 |
||
BORE/STROKEmm |
145/183 |
DISPLACEMENTL |
18.1 |
||
EXHAUST AIR FLOWm3/min |
564 |
COMPRESS AIR FLOWm3/min |
41.3 |
||
EXHAUST GAS FLOWm3/min |
90 |
EXHAUST GAS HIGHEST TEMPERATURE() |
459 |
||
LUB-OIL PAN CAPACITY(L) |
68 |
ING WATER CAPACITY(L) |
71.6 |
||
VOLE FOR START(V) |
24 |
INSTRUMENT FOR ADJUSTING SPEED |
ELECTRONIC INJECTION |
||
NOISEdb(A) |
≤95 |
|
|
||
ALTERNATOR (LEROY SOMER) | |||||
MODEL |
LSA47.2S5 |
EXCITATION |
BRUSH-LESS |
||
INSULATION CLASS |
H |
VOLTAGE ADJUST RANGE |
≥±6% |
||
FROTECTION CLASS |
IP23 |
STEADY STATE VOLTAGE REGULATION |
≤±1% |
||
EFFICIENCY |
92.8% |
VOLTAGE CONTROL |
AVR |
||
Engine Features:
1. World most famous brand diesel engine: UK engine
2. Multi-cylinder in-line or veer engine, 4-stroke, direct injection
3. Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
4. Machinery or electronic governing
5. Fuel injection pump
6. Electric motor starting system
7. Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
8. Low discharge, and low fuel consumption
9. Installed conveniently and maintain easily
Alternator Features:
1. World famous brand AC alternator: Leroy Somer, Stamford, Marathon, ENGGA
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤±1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof
