16kva-1000kva 1MW CE&ISO Chinese Generator Diesel

Name: 16kva-1000kva 1MW CE&ISO Chinese Generator Diesel
Brand: China WC
SKU: 129242501
Availability: InStock

US$ 940 - 8,750 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

China WC

Model Number:

SMP, Saint Meilan

Fujian Saint Meilan Motor Wiring Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name China WC

Model Number SMP, Saint Meilan

Output Type AC Three Phase

Speed 1500RPM/1800RPM

Frequency 50/60Hz

Rated Power 16kw to 108kw

Rated Voltage 230V/400V,277V/480V

Rated Current 20-600A

Specifications

China engine diesel generator
1 generator:stamford,leory somer
2 one year warranty
3 CE and ISO
4 water-cooled,silent

16kva-1000kva 1MW CE&ISO Chinese generator diesel

Model		SML50E
Rated output (KW/KVA)		50/62.5
Rated voltage (V)		400/230
Rated current(A)		90.2
Rated frequency		50Hz/60Hz
Power factor		0.8lagging
Noisy level dB(a)		80/1m
Excitation		Brushless self-excitation
Phase Number and connection		3-phase 4-wire system
Diesel Engine		R6105D1-1,Water cooled type,Nature Intake Made by WEICHAI
Alternator model		Dingol (DG224E)
Rated Power (kw/1500rpm)		84
Fuel consumption (g/kw*h)		≤232
Cylinder number		6
Displacement ( L)		6.5
Cooling system		Water cooling
Environmental Conditions		Altitude≤1000M, Cooling air temperature -15°C~ 40°C, Relative humidity≤90%
Start Method		24V Electric start
Dimension of set (mm)	L	3000
	W	1000
	H	1700
Net weight of set (kg)		2050
Other spare parts (1 piece)		Gallus Air filter element Diesel oil filter element Machinery oil Specification Special tool
