AS480 AUTOMATIC VOLTAGE REGULATOR (AVR) FOR GENERATOR(Nupart Carton/nomal Carton)

AS480 AUTOMATIC VOLTAGE REGULATOR (AVR) FOR GENERATOR(Nupart Carton/nomal Carton) thumbnail-1
AS480 AUTOMATIC VOLTAGE REGULATOR (AVR) FOR GENERATOR(Nupart Carton/nomal Carton) photo-1
US$ 54.99 - 60.99 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Stanford
Model Number:
AS480
Contact Supplier Request Quote Chat Now
Fujian Saint Meilan Motor Wiring Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
fuzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Stanford
Model Number AS480



AS480 AUTOMATIC VOLTAGE  REGULATOR (AVR) FOR GENERATOR(Nupart Carton/nomal Carton)





Technical Date:



 Sensing Input

 Voltage

 100-264 V ac 1 phase

 Frequency

 50-60 Hz nominal

 Output

 Voltage

 82 V d.c. @ 200 Va.c power input; 45 V d.c. @ 110 Va.c power input.

 Current

 Continuous 5A , transient 7.5A for 10 secs.

 Resistance

 15 ohms minimum

 Regulation

 +/- 1%

 Thermal Drift

 0.03% per Deg. C change in AVR ambient

 Typical system
 Response

 AVR response

 20ms

 Filed current to
 90%

 80 ms

 Machine Volts to
 97%

 300ms

 External voltage adjustment

 +/-10% with 1 k ohm 1 watt trimmer; Increasing resistance lowers voltage; Fixed 15kOhm resistor enables 110V sensing

 Under frequency protection

 Set point:  94 -98% Hz

 Unit power dissipation

 12 watts maximum

 Build up voltage

 4 Volts @ AVR terminals

 QUADRATURE DROOP INPUT

 10 ohms burden

 Max. sensitivity: 0.07 A for 5% droop 0PF

 Max. input: 0.33 A

 Over Excitation
 Protection

 Set poit

 67 Vdc +/-3% (fixed)

 Time Delay

 10-15 seconds (fixed)

 Environmental

 Vibration

 20-100 Hz,50mm/se

 100Hz – 2kHz, 3.3g

 Operating
 Temperature

 -40 to +70 Deg. C

 Relative Humidity
 0-70 Deg. C

95%

 Storage
 Temperature

 -55 to +80 Deg. C



Why to choose us ?

1.Founded in 2005,with full experience of 10 years in manufacturing generator spare parts.

2.Started export since the year of 2008,with quick response to serve the oversea customers

3.Have already passed the strict quality inspection of ISO9001:2000 quality management system

4.Strong R&D Team to design and test products

5.Professional designers and technicians to provide technical assitance

6.Strict quality control process with strict standards

7.Strong installation consulting support

8.Quick after-sale technical advice and guidance

Payment Terms

 1.We accept Alipay, West Union, TT.

 2.All major Credit cards are accepted through secure payment processor ESCROW.



Shippment Terms



1. We Ship to Worldwide, besides APO/FPO (^_^)

2. Orders processed timely after showing remittance copy.

3. We only ship to confirmed order addresses. Your order address MUST MATCH your address.



Guarantee

1. Guarantee:1 year after selled.

2. During guarantee,the items share free repairs or replacement.

3. Customer is responsible for the freight come-and-go,and the custom tax.

4. You may consider to send the defective item with a economical way,and we send back the repaired items with your new order together.

5. To save the cost,pls send the item back without packing.

6. Pls provide the defective appearance and related invoice number.

7.We do not repair or replace item with an expired warranty.

8.All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email or give us a call any time.
