genset controller and battery charger 5A price Manufacturer

FOB Price

USD $19 - $29 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Fuzhou Sea Port
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Fujian, China	Brand Name:	Deutz, Isuzu, Deutz	Model Number:	SMD, SMD
Output Type:	AC Three Phase	Speed:	1500RPM/1800RPM	Frequency:	50/60HZ
Rated Power:	50kva--1000kva	Rated Voltage:	110V/240V, 220V/380V, 230V/400V, 240V/415V	Rated Current:	25-2000A

Product Description

Genset controller and battery charger 5A price Manufacturer

Place Sample Order On Line :Click

Generator charger introduction

Intelligent Charger is specially designed for starting or working of storage battery (especially suited for full-sealed solid wide-temperature storage battery) in diesel engine. It is a intelligent mode of switch structure. It features in constant pressure, constant current, tricking current, resistance of short circuit, and fully automated function.

Generator charger specification

Power Input	Voltage 160~250 VAC Frequency 20~100Hz
DC Output	Voltage 13.8 VDC, Current 5A--when battery group=12V Voltage 27.6 VDC, Current 3A--when battery group=24V
Charge Mode	Float charge
DC Voltage Regulation	< ±1%
Efficiency	> 80% @ Full load
Contact Capacity	0.5A @ 120 VAC
Protection	Reverse polarity, over-voltage, short circuit, current limiting
Environment	Operating Temperature : 0~40 °C Storage Temperature : -20~60 °C Relative Humidity : Maximum 90% Vibration : 1.5G @ 5~30 Hz / 5.0G @ 30~500 Hz
Dimensions	180(L) x 160(W) x 60 (H) mm

Main advantages

· Short Circuit & Reverse Polarity Protection

· Automatic Charging Under All Conditions

· Automatis identify charging voltage of battery group and putout 12V/24V

· Compact Size & High Efficiency

· Low Battery Voltage Monitor With Dry Contacts Opening or Closing Under Fault

· Charging Current LED Indicators
