Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 150KVA Low Noise Power Generator R6113ZLD

150KVA Low Noise Power Generator R6113ZLD

Name: 150KVA Low Noise Power Generator R6113ZLD
Brand: weifang
SKU: 129241301
Availability: InStock

150KVA Low Noise Power Generator R6113ZLD thumbnail-1

150KVA Low Noise Power Generator R6113ZLD photo-1

US$ 2,000 - 20,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

weifang

Model Number:

GF3-W100

Contact Supplier Request Quote Chat Now

Fujian Saint Meilan Motor Wiring Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name weifang

Model Number GF3-W100

Output Type AC Three Phase

Speed 1500 1800r/m

Frequency 50 60hz

Rated Power 100KVA

Rated Voltage 400/230v

Rated Current 37A

Specifications

low noise power generator
1.brushless alternator
2. Weifang engine
3. Low price
4. one year warranty

150KVA low noise power generator R6113ZLD

Out ATS Generator Control

1. automatic cutter which is suitable for the generator power
2. Turn on key
3. A device to measure the generators speed
4. Counter for measuring the Operating hours
5. Device to measure the current overload with a switched current
6. A device to measure the battery voltage
7. Voltmeter with a voltage exchanger
8. A device to measure the frequency
9. Thermostat to regulate the voltage
10. A device to measure the oil pressure
11. Alerting lamps indicating low and high temperature
12. Controller of the current increase and short circuit
13. Emergency stop button

Diesel Generator General Data Sheet

Weifang Series Alternator Generator
Genset Model	Rated Power		Standby Power		Fuel cons	Engine Model	Bore×Stroke (mm)	Displacement (L)	Dimensions	weight
Genset Model	Kw	KVA	Kw	Kva	≤ g/Kw.h	Engine Model	Bore×Stroke (mm)	Displacement (L)	(L×W×H)mm	Kg
SML-W20	20	25	22	27.5	258.1	495D	95 × 115	3.26	1780×750×1150	820
SML-W24	24	30	26.4	33	258.4	K4100D	100 × 115	3.61	1780×750×1150	900
SML-W30	30	37.5	33	41.3	251.6	K4100D	100 × 115	3.61	1950×800×1190	980
SML-W40	40	50	44	55	232	K4100ZD	100 × 115	4.33	1950×850×1350	1050
SML-W50	50	62.5	55	68.8	220	R4105AZD	105 × 130	4.33	1950×850×1350	1080
SML-W60	60	75	66	83	224	R6105ZD	105 × 125	6.49	2450×900×1400	1230
SML-W70	70	87.5	77	96.3	224	R6105ZD	105 × 125	6.49	2450×900×1400	1460
SML-W80	80	100	88	110	218	R6105AZLD	105 × 130	6.49	2500×900×1400	1590
SML-W90	90	112.5	99	124	218	R6105AZLD	105 × 130	6.49	2500×900×1400	1640
SML-W100	100	125	110	138	218	R6105IZLD	105 × 135	6.49	2500×900×1400	1710
SML-W120	120	150	132	165	218	R6113ZLD	113 × 125	6.49	2600×900×1450	1790

Accessories:

1)Standard accessories: Standard 40 radiator mounted on skid. Common steel frame, circuit nreaker, damper, exhaust silencer, flexible pipe,battery and connecting wire, Standard tool skit, operation manual and document

2) Optional accessories: Engine collant and oil heater, alternator space heater, cooling for heating exchange, communictaion interface, battery charger by main supply, daily fuel tank, ATS and paralleling system,soundproof canopy and moving trialer

Warranty policy:

Guarantee for one year or 1200 hours (accord to whichever reach first)from ex-factory date.During the guarantee period,our company will provide the free easy-damaged spare part for problems caused by our quality of production or raw material,except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation.After expiration,our company provides cost spare parts maintenance for gen-set.

Mobile Trailer Units (Optional)

Mobile generating sets are available throughout the full kva rating of the Saint Meilan range. Trailers (2 to 6 wheel) meet all relevant road traffic regulations and are generally used in conjunction with with weatherproof canopies or sound shields.

We offer several different trailer options, namely basic braked and none braked site trailers which are only suitable for off highway use due to the lack of lights etc., then there are full EC and none EC trailers which are suitable for on highway use depending on which Country the unit will be used in.
