230v/380v STC synchronous generator
- 7000 Piece / Pieces per Month
- any port in China
- T/T
Product Details
Place of Origin: | Fujian, China | Brand Name: | generator | Model Number: | stc-24kw |
Output Type: | AC Three Phase | Speed: | 1500rpm | Frequency: | 50hz |
Rated Power: | 24kw | Rated Voltage: | 380v | Rated Current: | 63.1A |
Product Description
Specifications
synchronous generator1.Metal Fan,Sealed Bearing
2.Balance rotor,copper stator winding
3.ce,iso9001
4.Pulley,AVR installed
230v/380v STC synchronous generator
generator which are mainly designed to serve as power generating
unit of small capacity which supply electricity for lighting purpose in ships as for household electric devices used in towns or villages
The construction of the generators is of drip-proof, salient pole rotating field self excitation and constant voltage type
Excellent appearance, consolidate in construction and easy to maintain.
OUTPUT: 1kw to 50kw (brush alternator )
.....................................................................................................................................
Environment Conditions:
Under the following environment,the generator could run continuously:
1.Altitude: not exceed 1000m.
2.Cooling air temperature: 258~313K(-15~40).
3.Relative air humidity :not exceed 90%.
..........................................................................................................................
Generators Specification
1)generator spare part: TERMINAL BOX COMP , carbon brush, carbon brush holder,copper ring,voltage meter,white rectifier
2)Alternator 3-Phase 4wire,Brushless ,H class Insulation ,Self-Extied ,IP23 Protection ,AVR regulation ,Voltage deviation:+5%,THF,5% low radio interference .
3)Frequency 50HZ &60HZ
4) Speed: 1500rpm /1800rpm
5)Three phase Voltage Available 208V /220V /230V/240V/380V/400V/415V/440V/460V/480V ,Single Phase Votage Available:100-250V
Model | Output | Current(A) | pole | speed(r.p.m) | |
kw | KVA | ||||
STC-3 | 3 | 3.8 | 5.4 | 4 | 1500 |
STC-5 | 5 | 6.3 | 9 | ||
STC-7.5 | 7.5 | 9.4 | 13.5 | ||
STC-10 | 10 | 12.5 | 18.1 | ||
STC-12 | 12 | 15 | 21.7 | ||
STC-15 | 15 | 18.8 | 27.1 | ||
STC-20 | 20 | 25 | 36.1 | ||
STC-30 | 30 | 37.5 | 54.1 | ||
STC-40 | 40 | 50 | 72.2 | ||
STC-50 | 50 | 62.5 | 90.2 |
Warranty policy
Guarantee for one year or 1200 hours whichever reach first from ex-factory date ,During the guarantee period ,Saint will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material,After expiration ,"Saint "provides cose spare pars maintenance of gensets.
Manufacturing standards
ISO9001 2008 ,CE ,GB/T2820,GB755 ,SONCAP ,AND SO ON.
