Specifications
ncentric neutral2. Professional QC/QA System
3.Promote delivery OEM
4.Certification: ISO9001
5.Best Serivce
Split Concentric Cable BS7870
Aluminum Strand core conductor concentric neutral of al wires
1. Standard :
IEC, BS or other standards as request.
2. Rated Voltage : 600/1000V
3. Construction :
Conductor:Aluminium
Insulation:PVC
Armoured:Aluminium wires
Outer Sheath:PVC
4. Characters :
a.Operating Temperatur: 70°C.
b.Short Circuit Temperature:160°C
c.DC Resistance at 20°C(.Min): 1.91 Ohm/km
d.Insulation Resistance at 20°C(Min): 5 Ohm/km
Split concentric cable to BS7870 suitable for power distribution as an underground cable
Conductors: Plain annealed copper
Insulation: PVC (Polyvinyl-Chloride)
Core identification: Brown
Concentric layer: Neutral conductor (blue) & an uninsulated CPC (Circuit protective conductor)
Sheath/Jacket: PVC (Polyvinyl-Chloride)
Colour: Black
Voltage: 600/1000v
Operating temperature: Maximum 70°C, minimum bending 0°C
Standard: BS7870 LV & MV polymeric insulated cables for use by distribution and generation utilities. Specification for multicore and multipair cables for installation above and below ground. Single wire armoured and PVC sheathed multicore cable with copper conductors
Applications: suitable for underground general use
