Specifications
tal engraving machine supplier2.Nc-studio Controil System
3.CE&ISO
Features:
1.The machine body structure adopt cast iron,
2.Well compatibility: compatible for software CAD/CAM, such as type3/artcam/JDPaint/proe/ug.rtc
3.. double nut screw to ensure the engraving speed. Adopting Taiwan’s high-precision square linear guide, .
4.Available for continuous work for a long time.
Technical Parameters:
NO. Description | Parameter | |
1 | Model | CX6060
|
2 | working area(mm) | 620*620
|
3 | Zaxis working area(mm) | 200 |
4 | Working accuracy | <=0.02mm |
5 | Location accuracy | <=0.01mm |
6 | Working voltage | AC220V/50HZ |
7 | Working speed | 8m/min |
8 | XYZrepositioning accuracy | 0.008mm |
9 | XYZTraveling positioning accuracy | 0.01mm |
10 | Spindle | 1.5kw constant power(here we offer you 1.5kw spindle,so the price is the same as 5040) |
11 | control system | NC studio control system+hand wheel+tool setting gauge |
12 | Guide | P grade square linear guide |
13 | Ball screw | TBI C5 Ground Ball Screws |
14 | Body | cast iron structure |
15 | Software | WENTAI ,Type 3,UG |
software | English software v9 | |
Machine:
sample
