MV Auminum XLPE Power Cable
Aluminum Conductor XLPE Insulated PVC Sheathed Power Cable NA2XSY
Conductor Material: Aluminum
Conductor Construction: Stranded, Class 2
Insulation: XLPE DIX8
Sheathing Material: PVC DMV6
Max. Temperature at Conductor: 90
Temperature, moved/during Installation:-5 to +70
Flame Retardant: VDE0482-332-1-2
Max. Operating Temperature, fixed: +70
Bending Radius, fixed installation: 15 x DA
CONSTRUCTION
Stranded Aluminum Conductor
Screen of Semi-Conducting Compound
XLPE Insulation
Screen of Semi-Conducting Compound
Screen of Copper Wire and Copper Tape
Sepration Tape
PVC Sheath
Rated Voltage: 6/10KV
Nominal Voltage Uo: 6KV
Nominal Voltage U: 10KV
Test Voltage: 21KV
Max. Permitted Operating Voltage in 3-Phase Systems: 12KV
Rated Voltage: 12/20KV
Nominal Voltage Uo: 12KV
Nominal Voltage U: 20KV
Test Voltage: 42KV
Max. Permitted Operating Voltage in 3-Phase Systems: 24KV
Rated Voltage:18/30KV
Nominal Voltage Uo: 18KV
Nominal Voltage U: 30KV
Test Voltage: 63KV
Max. Permitted Operating Voltage in 3-Phase Systems: 36KV
Application: For installation in ground, in water, outdoors, indoors and in cable ducts for power stations, industry, and distribution networks. The good installation properties of this cable make installation easy, even on difficult routes. Accc. to VDE 0276-603 cables must be protected against direct sun irradiation.
Rated Voltage 12/20KV Tech. Specs.
No. of Cores * Nominal Cross Section mm2 |
Outer Diameter mm |
Cu/Al Weight Kg/km |
Cable Weight Kg/km |
1x50 |
29 |
182/145 |
970 |
1x70 |
31 |
182/203 |
1100 |
1x95 |
32 |
182/276 |
1200 |
1x120 |
34 |
182/348 |
1350 |
1x150 |
35 |
182/435 |
1450 |
1x185 |
37 |
182/537 |
1650 |
1x240 |
40 |
182/696 |
1850 |
1x300 |
42 |
283/870 |
2200 |
1x400 |
45 |
394/1160 |
2600 |
1x500 |
48 |
394/1450 |
3000 |
