Home > Products > LED Modules > ws2801 led module 4 leds full color with drive IC full color led display module
ws2801 led module 4 leds full color with drive IC full color led display module
USD $0.7 - $0.9
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- shenzhen baoan port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Model Number: | M3535-2801 | Chip Material: | GaP | Emitting Color: | Other, white |
| Luminous Intensity: | 6000-7000mcd | Luminous Flux(lm): | R20/G40/B17 lm | Optical Attenuation(%): | 11 |
| Power: | 3W | Power Dissipation: | 0.96w | Color Rendering Index(Ra): | 80 |
| Color Temperature: | 3000-15000k | Operating Temperature(℃): | -10, 40 | Storage Temperature(℃): | -20, 40 |
| Brand Name: | iPixel LED | Certification: | CE |
Product Description
ws2801 led module 4 leds full color with drive IC full color led display module
Features
- Control IC included, supporting numerous
Color-change effects;
- Pcontrol by SD controller,Arduino,DMX512,Artnet
- Flexible PCB white color, 5V low voltage input;
- Every 1 Leds linear separable, custom-length
available;
- Eco-green light, no UV, IR;
- Extremely long lifespan & lower power
consumption
Parameter
| Light source | Epistar 5050 SMD LEDs |
| Beam angle | 120 deg. |
| Operating voltage | DC12V |
| IC Model | Ws2801 |
| Pixel pitch | P80mm |
| LED quantity /pcs | 4 pcs |
| Operation Temperature | -10℃-40℃ |
Pictures
