SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights

SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights thumbnail-1
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights thumbnail-2
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights thumbnail-3
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights thumbnail-4
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights photo-1
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights photo-2
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights photo-3
SMD 5050 Smart Flexible 8 * 32 RGB Micro Led Flashing Panel Lights photo-4
US$ 50 - 65 MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
Epistar 5050
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Contact Supplier Request Quote Chat Now
Shenzhen IPixel LED Light Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar 5050
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 51W/Max
Lamp Luminous Flux(lm) 6000
Color Temperature(CCT) full color
Working Temperature(℃) -40, 40
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color Changeable
Brand Name iPixel LED
Model Number S832WS2812

 SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights

Product Description



  this 8x32 pixel WS2812B flexible LED panel is a great way to add an impressive amount of color while still being able to individually control each LED.

We aren’t kidding around, that’s 256 individually addressable LEDs on a 320mm x90mm 90mm flexible panel.

You can create animations, games, or even incorporate them into a fun e-textiles project. On top of all that,thanks to its flexible backing, this LED Matrix can be bent and bowed to fit onto almost any curvy surface.

These panels require a 5V low voltage input for power which needs to be able to source a good amount of current– up to 5A in most uses (15A if all LEDs are set to bright white, which is NOT recommended).

Attached to each flexible LED matrix are two 3-pin JST SM connectors and two sets of bare power cables (input / output), which provide you connections for DC5V+, COM-, DAT, and GND. Needless to say, if you are looking for a large panel of addressable LEDs to fit the contours of almost any surface you’ve come to the right place.

Note: Repeated / Over bending may significantly reduce the structural integrity of the flexible panel. It is advisable when

bending it over curved surfaces to not be too rough with this product as you may damage LED traces or the panel itself.

Needless to say, do NOT fold this matrix in half!

product features



Product Name

8*32 pixel flex led matrix

Model Number

S832WS2812

Led Qty

256pcs (8x32 pixels)

Voltage(V)

DC5V

Watts

51W/Max

IC Chip

WS2811 IC built in 5050 RGB LED

IP Rate

IP20 (Non- waterproof)

PCB Color

Black PCB

PCB Width

10mm

LED Singal

SPI

View Angle

140°

Connector

3 Pin JST famale and male connectors

PCB Size

10mm

PCB Color

Black PCB

Brand

iPixel LED

Warranty

2 years
product pictures

 8*32 led panel light

SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights





5050 black pcb rgb led panel

SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights



 3-pin JST SM connectors

SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lightsSMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lightsSMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights



ralated product



8*8 led panel light

SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights





16*16 led panel light

SMD 5050 smart Flexible 8 * 32 RGB micro led flashing panel lights
