Home > Products > Digital LED bar > DMX control 48ledsDMX Vertical tubeTV Show Back gound
DMX control 48ledsDMX Vertical tubeTV Show Back gound
- shenzhen baoan
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
2016 New product DC 5V2812 RGBLed rigid bar
-
2016 Digital Addressable Full Color RGB Color running led digital Programmable
-
programmable led light controller T4000C with SD card
-
SPI signal SD card 8 output ports pixel led controller T-8000 offline control
-
t-300k led pixel controller
-
led lighting edit softwre master and slave control controller
Product Details
| LED Light Source | Epistar SMD 5050 RGB | Input Voltage(V) | DC24V | |
| Lamp Power | 19 | Lamp Luminous Flux(lm) | R800G2100B480 | |
| Lamp Luminous Efficiency(lm/w) | 20 | Color Temperature(CCT) | Other, white | |
| Working Temperature(℃) | -30, 55 | Working Lifetime(Hour) | 17000 | |
| Lamp Body Material | PVC | IP Rating | IP65 | |
| Certification | CE | Emitting Color | Changeable | |
| Brand Name | iPixel LED | Model Number | B4816V12 |
Product Description
DMX control 96 leds 360 view DMX Vertical tubeTV Show Back gound
1-This DMX Control LED Tube designed by clear PC tube
2-The whole tube had 16 Pixel which is 48CH DMX address
3-48pcs supper bright Epistar SMD RGB LED (one side)
4-Both side 96pcs LED make it 360 viewing
5-Each tube included 1pcs eye hook for installation
6-Every dmx tube attached a waterproof 5Pin connector (black color)
7-The length of connector 20cm,5Pin 20AWG copper wire
8-The tube didn't attach any T type (3 way) connectors for power injection
it request to purchase seperately
9-The diameter is tube is 30mm (we also offer 23mm diameter size)
10-Avaliable size : 50cm & 100 cm
| Part Number | B4816V12-A |
| Emitting Color | Full color |
| LED type | 5050RGB |
| MCD per LED | R800/G2100/B480 |
| Pixel | 16Pixels |
| watts | 19W |
LED Tube
