Specifications
1.Oversea Branch Office.2.CE&ISO Certificate
3.Factory established in 1991.
4.Products in Stock
China Manufacturer CNC Aluminium Windows Double Head Cutting Machine
1.High quality, Fair Price, Fast Delivery.
2.OEM Service, Trail Order
3.The Color, The logo, The package according to your request,
4.We are the Manufacturer,We have many engineers for the solutions for the new market to keep the trend of the world.
As a factory, We are looking forward to finding the agents of our products all over the world!!
Features and functions:
1. The machine is the most advanced double-head cutting saw
2. The machine adopts Europe model with neat appearance and good style
3. The control system adopts the new closed-loop system
4. The directly connection blades adopt lever-swing cutting type
5. The feeding of the blade is driven by hydraulic damping cylinder, with smooth cutting
6. The imported high precision blade makes the cutting surface more smooth
7. The cutting angle is auto adjustable through the imported servo motor between 45°-157.5°
8. Several profile processing dimensions can be input in one time and make continuous cutting
9. The processing dimension can be directly input, the cutting length can be changed without returning the reference point
10. The right cutting head is driven by the imported servo motor, features high speed and precison
11. The airproof device under the worktable has wonderful crumbs-cleaning effect
12. The following saw cover keeps it working in the clean environment
13. The stuff following-up supporter can reduce the machine space
14. The profile was clamped by two cylinder in every head, and kept the cutting security
Technical parameter:
Power supply |
380V 50Hz |
Cutting motor power |
2x2.2Kw |
Rotary Speed |
2800r/min |
Servo motor power |
3x0.75Kw |
Rotary Speed |
4050r/min |
Air pressure |
0.5-0.8Mpa |
Air consumption |
60L/min |
Cutter feeding speed |
stepless speed regulation 0-0.3m/min |
Cutter moving speed |
0-20m/min |
Cutting length |
max 4500mm min 360mm at 90° max 4200mm min 760mm at 45° |
Cutting width |
135mm |
Cutting height |
230mm |
Cutting angle |
45°-157°5 any angle in the range |
Repeat locating length tolerance |
±0.2mm |
Cutting profile surface plane |
<=0.10mm |
Cutting angle tolerance |
±0.5′ |
Cutting profile surface roughness |
Ra 12.5μm |
Overall dimension |
6800X1500X2040mm |
Weight |
2500kg |
Machine Images
Auminum window processing equipments
The Seller shall provide all spare parts needed, be responsible for spare parts replacement and TWELVE (12) months guarantee.
After guarantee period all costs of replacement, cost of spare parts, shipment cost, and others cost shall be covered by Buyer.
The seller will supply free online technical service, free training program for the buyer’s staff , on-site installation.
Jinan Liaoyuan Machine Co.,Ltd Attend Annual Exhibition
