1,Concrete pipe machines
2,Concrete Pipe Machine Manufacturer
3,pipe diameter:300-2000mm
4,rolling speed:62-727r/min
ISO&BV
1, The Characteristics of XG series of concrete pipe machine
XG series of concrete pipe machine compact materials into shape by means of pressure and centrifugal
force generated by roll shaft and steel mold, and bring shaped pipes to standard strength by steam or natural
curing and finally produce reinforced concrete pipes 1000-2000mm long with 300-2000mm inner diameter with average efficiency of one section every ten minutes. The machine is easily
operated, running smoothly, reliable and endurable with low failure rate.
Specific parameters shall comply with the attached table
2,Product Introduction:
The concrete pipe machine manufacturing machine of roller hanging type XG series utilizes the rotation of roller axle and steel mould to produce rolling pressure and centrifugal force and makes the mixed cement material shape into a pipe.Through steam or natural maintenance,make theshaped pipe up to the standard intensity.Our compang can produce the armored concrete pipe of 300-2400mm in internal diamete and 1000-5000mm in length.The averaga efficiency id one section/10 minutes.this machine is simple in operation,rotates steadily, is reliable and durable in use,is low in fault rate
Produce scope:length 2m,3m,4m,5m;30-80cm 80-120cm 120-160cm 160-200cm flat head,connection-peg and various c20,c30,c40 concrete canal.
Advantage of technique:
1.roller center-fixed and revolve-lockde.Supply material mechanized.
duce 4m-5m single canal by using a mold,or pro-duce either 2m+2m two sections canal.
Power:15kw -85kw single or double sets electromagnetic timing engine
Produce efficiency:1 section or 2 sections of canal during 10min to 25min
3.Main technical parameters of concrete pipe machine:
Model |
XG(Φ300-800)x2000 |
XG(Φ800-1200)x2000 |
XG(Φ1200-1650)x2000 |
XG(Φ1650-2000)x2000 |
Pipe diameter(mm) |
300-800 |
800-1200 |
1200-1650 |
1650-2000 |
Roller diameter(mm) |
127 |
219 |
273 |
325 |
Pipe length(mm) |
1000-2000 |
1000-2000 |
1000-2000 |
1000-2000 |
Motor power(kw) |
15 |
18.5 |
55 |
75 |
Rolling speed(r/min) |
62-618 |
62-618 |
72-727 |
72-727 |
Dimension (mm) |
4100x2350x1600 |
4100x2350x1850 |
4550x3500x2500 |
4550x3500x2900 |
