Fuel Level Sensor for Vehicle,truck,taxi,carFuel Tank Level MonitoringUltrasoniliquid Level SensorUltrasonic Fuel Level Detector

US$ 67.99 - 80 MOQ: 1000 Sets

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

DYP

Model Number:

DS1309A

Shenzhen Dianyingpu Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name DYP

Model Number DS1309A

Features:

1) Measuring precision, measurement resolution is 0.1mm, liquid level measurement accuracy is 0.5%.

2) Good stability; 3) Easy to install; 4) Simple application; 5) Strong antistatic ability (EMC);

6) Variety of standard signal output ways, which are analog voltage (1-5V) and current (4-20mA), digital output RS232 and RS485;

Technical parameters:

Operating Voltage		DC9V-36V
The power supply ripple		Less than 100mV
Operating current		Less than 55mA
Measuring distance		3cm to 100cm; pressure-bearing range: -0.1MPa~32MPa
Resolution		0.1mm
Measurement accuracy		0.5%
Temperature compensation range		-40 - +80°C
Output mode		analog voltage,current,RS485,RS232
Analog output	Voltage output (default)	1-5V (corresponding 0-100cm)
	Current output	4-20mA (corresponding 0-100cm)
Digital output	RS232(default)	See the “communication protocol”
	RS485
Alarm output		need external connection a alarming horn to achieve alarm
Install method		bottom of fuel tank/can, water tank
Operating temperature		-40 - +80°C
Storage temperature		-50 - +100°C
Size		1024825mm with mounting holes
