Digital ultrasonic/liquid level sensorNon contact ultrasonic fuel level sensor for fuel consumption monitorUltrasonic fuel level

Operating Voltage

DC9V-36V

The power supply ripple

Less than 100mV

Operating current

Less than 55mA

Measuring distance

4cm to 100cm;

 pressure-bearing range: -0.1MPa~32MPa

Resolution

0.1mm

Measurement accuracy

0.5%

Temperature compensation range

-40 °C-  +80 °C

Output mode:

Analog output

Voltage output

(default)

1-5V (corresponding 0-100cm)

Current output

(optional)

4-20mA (corresponding 0-100cm)

Digital output

RS232(default)

See the “communication protocol”

RS485(optional)

Anti-theft alarm output

need external connection a alarming horn to achieve alarm

Install method

bottom of fuel tank/can, water tank

Operating temperature

-40 °C - +80 °C

Storage temperature

-50 °C - +100 °C

Size

102*48*25mm (with mounting holes)

Cable length

8m, with shield

Gross weight(G)

About 770g
