Specifications
With an external serial download port, two switch outputs, three button selections and two IO ports extension.1 Small and light appearance, it is easy to use;
2 Operating Voltage: DC 7-12 V;
3 Current: 50 mAh;
4 Maximum Test Distance: 500 cm;
5 Size (L x W x H): Approx. 5 x 4.4 x 1 cm / 2 x 1.7 x 0.4 inch;
6 With an external serial download port, two switch outputs, three button selections, two IO ports extension and temperature compensation function;
Operation:
1 This module's outputs can be use-defined;
2 Press and hold S1 button for 3 seconds, showing LLL;
3 Press S1, it displays a number (001 e.g.), which is the asuring value. When the measured distance is less than this value,OUT2 will output a high level (4.5V). The min. measurement value is adjustable, press S2 to increase, S3 to decrease;
4 Press S1 again after the min. measuring value is set, it displays HHH, then press the S1 to indicate a number (200 e.g.), which is the max. measurement value. When the measuring distance is larger than this value, OUT1 will output a high level (4.5V). This Max. measuring value is adjustable, press S2 to increase, S3 to decrease;
5 When the max. measuring value is settled, press S1 to save. This device is designed with memory function when power off;
