Help CenterGH-311 Ultrasonic Sensor Spot SupplierRoborts SensorUltrasonic Sensor Distance Measuring ModuleGH-311 Ultrasonic Sensor Module
Related Products
-
125KHz High Frequency and Accuracy Ultrasonic Sensor ModulUltrasonic RS232Waterproof Ultrasonic Sensor Distance Measuring ModuleUS$ 44.45 - 72.97MOQ: 100 Sets -
Cheap Ultrasonic SensorsUltrasonic SensorDistance Measuring SensorObstacle Detection SensorSUltrasonic TransducerSensorUS$ 2.71 - 7.25MOQ: 2000 Pieces
-
Range Distance Detect Ultrasonic Sensor Display ModuleDisplay Distance BoardSensorsUltrasonic Sensor LED Security Display ModuleUS$ 5.65 - 7.23MOQ: 1000 Pieces
-
USB Interface Ultrasonic Sensor Module/Ultrasonic Sensor/Professional Sensor Manufacturer Producing/High Quality and Best PriceUS$ 7.26 - 11.29MOQ: 500 Pieces
-
Ultrasonic Sensor ModuleUltrasonic Sensor Module With a Long-termUltrasonic Distance SensorWaterproof Ultrasonic Sensor ModuleUS$ 10.03 - 15.94MOQ: 500 Sets
Specifications
This sensor is a non-contact distance sensing module and having the feature of high performance and cost-effective.Description:
This ultrasonic ranging module is a non-contact distance sensing module and having the feature of high performance and cost-effective. Measuring range is 0.02 ~ 4.00m, measurement accuracy is 0.5cm. When it works,it does not contact with the measured object directly,and it could show the results of measurement clearly.
Features:
1/ Small size, easy to use;
2/ Low voltage, low power consumption;
3/ Wide measurement range;
4/ High accuracy;
5/ Small blind;
Applications:
1/ Application in the occasions of waterproof;
2/ Measuring the space between objects;
3/ Programmable car obstacle avoidance;
4/ Robot obstacle avoidance;
5/ Teaching apparatus;
6/ Security, industrial control;
Electrical parameters:
Operating voltage |
DC 5V – 12V |
Operating current |
3mA |
Operating frequency |
40KHz |
Ranging range |
2cm - 4m |
Resolution |
1mm |
Measuring angle |
30° |
Mode of output |
switch output |
Response cycle |
100ms |
Operating temperature |
-10°C - 60°C |
Storage temperature |
-20°C - 80°C |
Size |
46mm X 19mm X 15mm |
