Coaxial Multi Video Transmitter and Receiverter 2ch/3ch/4ch

Coaxial Multi Video Transmitter and Receiverter 2ch/3ch/4ch thumbnail-1
Coaxial Multi Video Transmitter and Receiverter 2ch/3ch/4ch photo-1
US$ 30 - 52 MOQ: 1 Pair
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
SD
Model Number:
SD-S700V2N
Contact Supplier Request Quote Chat Now
Beijing Briar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name SD
Model Number SD-S700V2N

2CH coaxial multi video transmitter and receiverter 2ch/3ch/4ch over coaxial

Product Description



1.Brief Introduction

The 2channels video multiplexer can realize transmit 2 channels Homonymous and reverse video signal in one cable at the same time, increase cable use radio effectively, there are characteristics HD image, convenient installation, without adjustment, stable and reliable etc.



 2.Characteristics

1,Transmit 2CH single or bi-direction video real-time HD signal in one coaxial cable;

2,Transmission distance up to 700m,still transmit 500m from the first channel(remark: multi-core video coaxial cable SYV75-5/3-2 have a short transmission distance, about 200m from main core)

3,Built-in anti-statics protection circuit

4,Without adjustment,have a stable working status;

5,HD image with built-in double seven order dressing filter.



3.Specification

Item

Unit

Parameter

Item

  Unit

Parameter

Output rate range

MHz

VIDEO2 0-8MHZ

VIDEO1 30-40MHZ

Power supply

    V

DC 12V

Output level range

dB

105

Actual working current

  MA

100ma transmitter

120ma receiver

Output impedance

Ω

75

Working temperature

  ℃

-30-50

OOB suppression degree

dB

>60

Transmitter size

  mm

90*51*24(not including joint)

Video input range

Vpp

0.8-1.5

Receiver size

  mm

90*65*24(not including joint)

Video output range

Vpp

0.8-1.5

Transmission distance

   m

700m(besides -2multi-core lines)



4.Connecting Diagram

coaxial multi video transmitter and receiverter 2ch/3ch/4ch



5.Notes

1.Payment Term: T/T,L/C,Paypal ,Western Union

2.Delivery time: Samples order within one workday

3.Packing: Neutral box packing and without any factory's information.

4.All of our products have one year quality warranty

5.Beijing Briar Technology Co.,Ltd. have the final explanatory power of specifications.



Packaging & Shipping



Packing Details: Box or Carton or As your required





Delivery Details:  Samples order within one workday
