Cheap PIR Motion SensorAdjustable IR Pyroelectric Infrared PIR Motion Sensor Detector ModuleSensorInfrared PIR Motion Sensor

Specifications

Description:

1 Infrared sensor with control circuit board;

2 The sensitivity and detection range are adjustable;

3 Detecting Range: Approx. 7m / 23 feet;

4 Detecting Angle: Less than 110 degrees;

5 Working Voltage Range: DC 4.5V- 20V;

6 Quiescent Current: Less than 60uA;

7 Level Output Voltage: High 3.3V / Low 0V;

8 Working Temperature: -20 to +80 degrees C;

9 Trigger Method: L unrepeatable trigger / H repeatable trigger;

10 PCB Size: Approx. 32mm x 24mm / 1.3 x 0.9 inch;

Features:

1 Small and light, it is easy to use;
2 Suitable for the field of security, toy, automation control etc. ;
