NMRV 030-130 worm speed reducer gearbox high quality and nice price
- shanghai
- T/T
You May Like
Product Details
| Gearing Arrangement | Worm | Output Torque | 0.29-2450Nm, by the Ratio | |
| Rated Power | 0.06-15kW | Input Speed | 1500 | |
| Output Speed | 14-186.7 | Model Number | RV | |
| Brand Name | KEYIDE |
Product Description
♦good quality
♦whoesales and retail
♦professional shopping guide
♦shipping fast
KEYIDE manufactures good quality Small to Large capacity NMRV Series Flange Mounted Worm Gear Reducer in china.
Features:
1.large speed ratio range
2.small volume,low weight ,saving space for mounting.
3.high efficiency,high mechanical strength and high quality aluminum alloy housing
4.long life service,large output torque,low noise and little vibration
5.low temperature rise,omnibearing installation ,easy to connect with other machinery.
6.high carry ability,elegant apperance.
7.CE standard,input power can be 0.06KW-15KW
8.stable transmission
Type: | RV Series Worm Gear Reducer |
Model: | NMRV030, 040, 050, 063, 075, 090, 110, 130 |
Ratio: | 1:5, 7.5,10,15,20,25,30,40,50,60,80,100 |
Color: | Blue/silver/green or on customer’s request |
Material: | Housing-aluminum with oven painting for RV030-090 gear reducer, cast iron for RV110 and 130 gear reducer. |
Worm Whele-ZQAl9-4-4-2 | |
Worm Shaft- 20Cr steel.The hardness of surface is 56-62HRC with carbonized layer 0.3-0.5mm | |
Bearing: | QC |
Oil Seal: | CTY |
Packing: | Inner pack: use plastic bag and foam box, Outer pack: carton or wooden case per set or based on customer's request. |
Warranty: | 1 year |
Application: | Industrial Machine: Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass. |
♦12 MONTHS WARRANTY PERIOD, AND WHOLE LIFE MAINTENANCE.
♦ 24 HOURS ON LINE SERVICE!
♦SWIFT FEEDBACK AND PROMPT TECHNICAL SUPPORT.
♦ FREE PARTS REPLACEMENT IN WARRANTY.
