Cold/Hot feed rubber extruder screw and barrel from China
- 120 Set / Sets per Month
- ANY CHINA PORT (NINGBO/SHANGHAI)
- T/T L/C D/P D/A Credit Card PayPal
- Low Price PVC WPC profile for Window and Door Profile Production Line making machine
- Double corner automatic plastic refrigerator gasket welding machine PVC gasket welding machine
- PLA PBS PBAT Starch Straw Sheet Extrusion Line
- Sheet Extrusion Line / APET PETG CPET sheet extrusion line
- Ice Chest/Freezer Sealing Strip Door Gasket Magnetic Strip Making Machine/Magnet Strip Extruder for refrigerator door gasket
- Magnet Strip Extruder for refrigerator door gasket
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | JS ALLOY | Model Number: | JS- |
Product Description
Specifications
1) type of screw: hot feed rubber extruder screw2) machine application: extruder machine
3) factory: jinsheng alloy
Hot feed rubber extruder screw and barrel by China
Specification: OD30MM-OD250MM
Ratio of length to diameter: L/D=15-45
We have kinds of screw type: common type,gradual type,sudden type,barrier type,pinned type,exhaustive type,BM type,separate type etc.
Based material: 1)38CrMoAlA
2)Cr12MOV
3)4Cr5MoSiV1
4)42CrMo
Surface Treatment : Heat Treatment
High Frequency Treatment
Nitriding treatment(120 Hours)
Hard Chrome Plating treatment
Nickel alloy plating.treatment
Technical Parameter: Depth of Nitrided Layer: 0.5-0.8 mm
Hardness of Nitrided Layer: 900-1020Hv
Thickness of Hard Chrome Plating Layer: 0.05-0.10mm
Hardness of Hard Chrome Plating Layer: ≥950HV
Bimetallic Barrel/Cylinder: Centrifugal Casting
Bimetallic Screw: Plasma Alloy Coating Spraying
Depth of Bimetallic Layer: 2-3mm
Hardness of Bimetallic Layer: HRC58-62
Hardness after Hardening & Tempering: HB260-290
Roughness of the surface:Ra0.4um
Linearity of the screw: 0.015mm
Linear axis limit: ≤0.02mm
Fragility of Nitration: Less than grade 1
1) wooden case package
2) plastic film package
3) as buyer request
All the goods will be packed by carefully that ensured the good quality to our customer.
Our other types for screw and barrel:
1) Bimetallic Screw and Barrel
2) Injection Screw and Barrel
3) Extruder Screw and Barrel
4) Conical Twin Screw and Barrel
5) Parallel Twin Screw and Barrel
6) Rubber Screw and Barrel
7) Planetary Screw and Barrel
8) Componetns
Jinsheng Bimetallic Plastic Machinery Factory was established in 2004. It was developed as a large-scale and comprehensive company specializing in manufacturing the kinds of Screws and Barrels in Zhoushan.such as bimetallic barrel & screw ,conical twin screws & barrels ,parallel twin screws & barrels,single screw &barrel , rubber screw & barrel ,planetary screw & barrel and components apply for injection molding machine and extruder machine .
Jinsheng Services and Advantage:
1) Jinsheng have more than 1 year quarantee
2) Jinsheng have over 10 years history
3) Jinsheng have a strong work-hard team
4) Jinsheng is the first factory to make the bimetallic screw and barrel
5) Jinsheng will handle all difficult for products
6) Jinsheng will meet customer request
7) Jinsheng will be keeping improving
1) Quality always comes first. Our experienced workers pay attention to every tiny procedure during the production and inspection, to ensure the precision of every dimension.
2) Service makes us outstanding. Our sales people are trained on the products every day. They are always ready to answer your questions and offer the best solutions in fluent English at any time.
3) Provide an easier working way. With 2 years export experience, we supply the easier working way to our customer. We are willing you to visit our factory at any time!
What is Jinsheng company CULTURE?
- Working Spirit :Responsibility,improvement
- Positioning :stability,development, international
- Culture feature: Working-Hard,Responsibility,Co-operation
- Competitiveness:Quality,Technology,Cost
Contact Us
- Zhoushan Dinghai Jinsheng Bimetallic Plastic Machinery Factory (General Partners)
- Contact nameHAPPY TU
- Phone86-580-8043200
- AddressNo6 LiuHang Road,XiHou Industry Zone,jintang Town ,zhoushan city Zhoushan,Zhejiang
