HUMAN MACHINE INTERFACE

TP series HMI

Model

Function

TP460-L

Touch panel, monochrom, 4.7 inch, 240*128 pixels, 15 word*8row

TP760-T

Touch panel, TFT true color, 7.0 inch, 480*234 pixels

MP760-T

Touch panel+29 key-press, TFT true color, 7.0 inch, 480*234 pixels, 20word*15row

TPA61-T

Touch Panel, TFT true color, 10.4 inch, 640*480 pixels, 40word*30row

TH series HMI

Model

Function

TH465-M

4.3 inch touch panel, 65536 TFT true color, 480*272 pixels, double USB data saving ports, one USB download port, 8MB memory, can extend to 1GB in max.

TH765-M

7.0 inch touch panel, 65536 TFT true color, 800*448 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.

TH865-M

8.0 inch touch panel, 65536 TFT true color, 800*600 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.

THA65-M

10.4 inch touch panel, 65536 TFT true color, 800*600 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.

OP series display monitor

Model

Function

OP320

3.7 inch monochrome LCD, 192*64 pixels, 7 function keys, RS232/RS422

OP320-A

3.7 inch monochrome LCD, 192*64 pixels, 20 function keys, RS232/RS422

OP320-S

3.7 inch monochrome LCD, 192*64 pixels, 7 function keys, RS232/RS485

OP320-A-S

3.7 inch monochrome LCD, 192*64 pixels, 20 function keys, RS232/RS485

MP330-S

Operate panel with touch function, 3.7 inch monochrome, 192*64 pixels, 24ASCII*4 lines, 26 keys, use OP software to program

MP360-L

Operate panel with touch function, 3.7 inch monochrome, 192*64 pixels, 24ASCII*4 lines, 26 keys, use TP software to program

OP

OP560-T

5.7 inch, 256 color LCD, 320*240 pixels, 42 function keys, 320*240 pixels, 4MB FlashROM, 2KB SRAM
