OPERATOR PANEL / Operator Interface

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Wuxi Lotus Import And Export Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Specifications

Our factory is the biggest HMI supplier in china,our price is very competitive with good quality

HMI

Rich sizes:3.7'' 4.7'' 5.7'' 7'' 10.4''

Display:Yellow-green STN,monochrome LCD ,65536 true color,256 true color

Fast response,fexible key-press

Digital touch style

OP key-press:42,20,7,the numeric keys can be defined as fuction

Memory space:maximum 8M flashROM,maximum 4K SRAM

OP: communication/download port

TP: comunication port,download/communication port

Support:RS-232,485,422

Built in TRC(real time clock)

TP series

TP series HMI	Model	Function
	TP460-L	Touch panel, monochrom, 4.7 inch, 240128 pixels, 15 word8row
	TP760-T	Touch panel, TFT true color, 7.0 inch, 480*234 pixels
	MP760-T	Touch panel+29 key-press, TFT true color, 7.0 inch, 480234 pixels, 20word15row
	TPA61-T	Touch Panel, TFT true color, 10.4 inch, 640480 pixels, 40word30row

TH series HMI	Model	Function
	TH465-M	4.3 inch touch panel, 65536 TFT true color, 480*272 pixels, double USB data saving ports, one USB download port, 8MB memory, can extend to 1GB in max.
	TH765-M	7.0 inch touch panel, 65536 TFT true color, 800*448 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.
	TH865-M	8.0 inch touch panel, 65536 TFT true color, 800*600 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.
	THA65-M	10.4 inch touch panel, 65536 TFT true color, 800*600 pixels, double USB data saving ports, one USB download port, 128MB memory, can extend to 1GB in max.

OP series display monitor	Model	Function
	OP320	3.7 inch monochrome LCD, 192*64 pixels, 7 function keys, RS232/RS422
	OP320-A	3.7 inch monochrome LCD, 192*64 pixels, 20 function keys, RS232/RS422
	OP320-S	3.7 inch monochrome LCD, 192*64 pixels, 7 function keys, RS232/RS485
	OP320-A-S	3.7 inch monochrome LCD, 192*64 pixels, 20 function keys, RS232/RS485
	MP330-S	Operate panel with touch function, 3.7 inch monochrome, 19264 pixels, 24ASCII4 lines, 26 keys, use OP software to program
	MP360-L	Operate panel with touch function, 3.7 inch monochrome, 19264 pixels, 24ASCII4 lines, 26 keys, use TP software to program
OP	OP560-T	5.7 inch, 256 color LCD, 320240 pixels, 42 function keys, 320240 pixels, 4MB FlashROM, 2KB SRAM
