Flange Ball Valve Stainless Steel Ball Valve
US$ 10 - 500
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Material:
Carbon Steel
Technics:
Casting
Type:
Flange
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainless Steel Butterfly ValveUS$ 1 - 1,000MOQ: 1 Piece -
Butterfly Valve Drawing 6 Inch Butterfly ValveUS$ 50 - 700MOQ: 1 Piece
-
Butterfly Valve for Cement Flange ConnectionUS$ 20 - 20MOQ: 1 Piece
-
Type A Manual-Operated Wafer Butterfly ValveUS$ 50 - 50MOQ: 1 Piece
-
Butterfly Check Valve Price Butterfly ValveUS$ 1 - 1,000MOQ: 1 Piece
Material
Carbon Steel
Technics
Casting
Type
Flange
Place of Origin
Fujian, China
Model Number
Cast steel ball valve
Brand Name
Minshan
Connection
Other, Flange, Flange end
Shape
Equal
Head Code
Square
Banner
Product Description
Flange ball valve stainless steel ball valve with ISO, CCC Certificates
| Model | Nominal Pressure | Testing | Temperature(°C) | Medium | ||
| Strength(Water)Mpa | Seat(Water.oil)(Mpa) | Low pressure seat(Water,oil)Mpa | ||||
| Q41F-16P(R) | 1.6 | 2.4 | 1.8 | 0.6 | ≤200 | Nitric Acid |
| Q41F-25P(R) | 2.5 | 3.8 | 2.8 | 0.6 | ≤200 | Nitric Acid |
| Q41F-40P(R) | 4 | 6 | 4.4 | 0.6 | ≤200 | Nitric Acid |
Material List:
| Parts | Material | |
| Q41F-16-25-40C | Q41F-16-25P-40R | |
| Body | Carbon stee | Stainless steel,Cr.Ni.Mo.Tisteel |
| Ball | ||
| Stem | ||
| Seat | PTFE | |
| Handle | Gray Cast Iron,Foged cast iron | |
Main Dimension:
| Model | DN | Size (mm) | |||||||
| L | D | D1 | D2 | H | b-f | Z-Φd | Do | ||
| Q41F-16P(R) | 15 | 130 | 95 | 65 | 45 | 60 | 2~14 | 4`14 | 108 |
| 20 | 140 | 105 | 75 | 55 | 64 | 2~14 | 4`14 | 120 | |
| 25 | 150 | 115 | 85 | 65 | 90 | 2`16 | 4`15 | 165 | |
| 32 | 165 | 135 | 100 | 78 | 105 | 2`16 | 4`16 | 180 | |
| 40 | 180 | 145 | 110 | 85 | 150 | 3`16 | 4`17 | 240 | |
| 50 | 200 | 160 | 125 | 100 | 190 | 3`16 | 4`18 | 240 | |
| 65 | 220 | 180 | 145 | 120 | 195 | 3`18 | 4`19 | 320 | |
| 80 | 250 | 195 | 160 | 135 | 215 | 3`20 | 4`20 | 350 | |
| 100 | 280 | 215 | 180 | 155 | 250 | 3`21 | 4`21 | 400 | |
| 125 | 320 | 245 | 210 | 185 | 280 | 3`22 | 4`22 | 500 | |
| 150 | 360 | 280 | 240 | 210 | 320 | 3`23 | 4`23 | 600 | |
| 200 | 400 | 335 | 295 | 265 | 370 | 3`24 | 4`24 | 800 | |
| Q41F-25P(R) | 40 | 180 | 145 | 110 | 85 | 160 | 3`25 | 4`25 | 240 |
| 50 | 200 | 160 | 125 | 100 | 205 | 3`26 | 4`26 | 270 | |
| 65 | 220 | 180 | 145 | 120 | 215 | 3`27 | 4`27 | 350 | |
| 80 | 250 | 195 | 160 | 135 | 230 | 3`28 | 4`28 | 400 | |
| 100 | 280 | 230 | 190 | 160 | 270 | 3`29 | 4`29 | 500 | |
| 125 | 320 | 270 | 220 | 188 | 300 | 3`30 | 4`30 | 600 | |
| 150 | 360 | 300 | 250 | 218 | 340 | 3`31 | 4`31 | 900 | |
| 200 | 400 | 360 | 310 | 278 | 400 | 5~34 | 4`32 | 1100 | |
| Q41F-40P(R) | 15 | 130 | 95 | 65 | 45 | 60 | 2`16 | 4`33 | 40 |
| 20 | 140 | 105 | 75 | 55 | 65 | 2`16 | 4`34 | 51 | |
| 25 | 150 | 115 | 85 | 65 | 90 | 2`18 | 4`35 | 58 | |
| 32 | 180 | 135 | 100 | 78 | 105 | 3`18 | 4`36 | 66 | |
| 40 | 200 | 145 | 110 | 85 | 170 | 3`18 | 4`37 | 76 | |
| 50 | 220 | 160 | 125 | 100 | 230 | 3`20 | 4`38 | 88 | |
| 65 | 250 | 180 | 145 | 120 | 250 | 3`21 | 4`39 | 110 | |
| 80 | 280 | 195 | 160 | 135 | 250 | 3`22 | 4`40 | 121 | |
| 100 | 320 | 230 | 190 | 160 | 295 | 3`23 | 4`41 | 150 | |
| 125 | 400 | 270 | 220 | 188 | 330 | 3`24 | 4`42 | 176 | |
| 150 | 400 | 300 | 250 | 218 | 375 | 3`25 | 4`43 | 204 | |
| 200 | 550 | 375 | 320 | 282 | 440 | 3`26 | 4`44 | 260 | |
