20 Bar Fog Nozzle for Cooling,humidifying Water Mist Nozzle,high Pressure Mist Nozzle

Name: 20 Bar Fog Nozzle for Cooling,humidifying Water Mist Nozzle,high Pressure Mist Nozzle
Brand: Mebon
Availability: InStock

FOB Price

US$ 0.8 - 1.5 / Piece

30 Pieces(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Mebon
Condition	New

Product Description

20 bar fog nozzle for cooling,humidifying water mist nozzle,high pressure mist nozzle

Product Description

Metal fog spray nozzle consists of brass/SS body with internal SS/ceramic core and stainless steel guide vane (with a leak-proof device).
The liquid flows at high velocity under the water pressure of 70kg to 120kg, forming centrifugal swirl and spraying very fine hollow droplet.
It is equipped with TEFLON strainer and the fog droplet sizes are about 30um.
Widely used in workshop moistening salt spray test,man-made fog and other moistening locations.
The imported US punching machine punches orifice about 0.15 to 0.5mm in size.
The nozzle saves 10 times or above cost than that of moistening by air.

Performance Data
Fog Nozzle	Orifice Diameter	Operation Pressure	Flow Rate
FD1	0.15mm	20-70kg/cm	20-46ml/min
FD2	0.20mm		49-89ml/min
FD3	0.30mm		80-145ml/min
FD4	0.40mm		95-178ml/min
FD5	0.50mm		130-243ml/min

Commen Application

1. Wetting & Rust removal

2.Humidify for space

3.Chemical treatment

4.Chemical agent spraying

5.Liquid coating

6.Humidify for tabacco leaf

7.Pill coating

8.Evaporative cooling for flue gas

9.Disinfection & sterilization

10.Parts cooling

11.Fruit wax injection

12.Ceramic tile glazing

13.Humidify for factory

14.Salt fog test

15.Artificial fog

16.Humidify for other place

Product Show

Artificial Fog by Our Nozzle
