Technical characters:
1. Germany's Siemens (SIEMENS) 840D CNC system.
2. Wheel spindle adopts high rigidity and precision electrical spindle which is supported by hydro-dynamic-static bearings. The built-in synchronous motor is inside the spindle.
3. The headstock spindle is equipped with self-developed electrical spindle supported by the hydro-dynamic-static bearing, with the Siemens servo motor.
4 .The flange disc can be installed both CBN wheel and ordinary grinding wheel.
Specifications:
Item | Unit | Spec. |
Parts diameter | mm | Φ20 - Φ80 |
Parts length | mm | 80-250 |
CBN Wheel size | mm | Φ500 × 203.2 × 30 |
Conventional wheel size | mm | Φ610 × 203.2 × 25-50 |
CBN wheel linear velocity | m/s | ≤100 |
Conventional wheel linear velocity | m/s | ≤60 Constant linear velocity |
Parts spindle rotate speed | rpm | 200-3000 |
Wheel and parts spindles feed speed | m/min | ≤36 |
Slide stroke of wheel and parts spindles feed | mm | 300 |
Total weight | Kg | 10000 |
Overall dimension | mm | 2900×2700×1900 |
