Home > Products > Polishing machine&Lapping machine > High Quality Single Side Lapping Machines for Industrial Use
High Quality Single Side Lapping Machines for Industrial Use
- Shenzhen Guangzhou Shanghai etc.
- Money Gram PayPal
You May Like
-
Factory Direct Sale Vertical Double Disc Side Surface Grinder
-
Best Selling Precision Lapping/Polishing Machine for Sales
-
High Efficiency Polishing Machine for the Flat Surface and 2.5D Arc Surface
-
Universal Grinder Machine in China
-
Professional CNC End Double Face Milling Machine
-
High Precision Automatic End Polishing Machine
Product Details
| Condition | New | Type | Surface Grinding Machine | |
| CNC or Not | CNC | Max. Grinding Diameter | 1800mm | |
| Place of Origin | Hunan, China | Brand Name | YUHUAN | |
| Model Number | YH2M81180 | Voltage | 380V 50Hz | |
| Power(W) | 18500 | Dimension(L*W*H) | 3000 x 2450 x 2500mm | |
| Weight | 9000kg | Certification | ISO9001:2008 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
polishing single surface for large-size glass.
Technical characters:
1.Single polishing head, workpiece is sucked on upper plate
2.Rotational speed of upper and lower plates is controlled by CNC program to meet different polishing process.
3.Pressurizing of upper plate to lower plate is accurately controlled by low friction cylinder and Electrical proportional valve
4.Lower plate is mounted on tray with reasonable design to make sure the run out of end face and the rigidity
5.Turn over type of loading and unloading
6.Linear movement of upper plate by servo motor and ball screw, load spread reasonably, good stability
7.HMI and PLC, easy to operate
8.Touch screen, it is convenient to show alert information and state. Besides, the interface is friendly and the information is huge.
9.24VDC of control components, PLC is supplied by isolation transformer, external electric wave interference is lowered, and the safety of the machine is greatly raised.
Our company has modern production workshop, Complex efficient grinding Laboratory , Computer Design Studio , has a variety of testing instruments and equipment over 30 sets of experimental facilities , a variety of processing equipment over 60 sets .
1.Fumigated wooden packages with IPPC stamp.
2.Special packing requirements available.
The R&D team has about over 50 engineers, occupied 20% of total staffs. Includes 19 SenierMechanical engineers( 4with doctor’s degree,8 with master’s degree),7 Senierelectrical engineers,5 CNC soft engineers
- The workshop and office area covers 20K Sqmeters.
- With over 270 staffs, including over 50 R&D technical engineers.
- Main products output more than 1000 sets per year.
Our R & D team establish a long - term partnership with National University of Defense Technology , Dalian University of Technology , Hunan University , Central South University , and other renowned institutions . Yuhuan is also research base for Hunan University’s doctoral student , get 5—9 patents per year .
- has got 36 related patents
- A certificate of international standard products in 2005
- has passed ISO9001 : 2000 international quality system certification, has estabished corporate product standards
Our products are widely used in automotive, IT electronic, military, and aerospace, shipbuilding, bearings,seals, household appliances, and other key areas of national economy.
Our products have been in great demand by more than twenty provinces including Taiwan all around China, and Vietnam, Portugal, Russia, Kenya, Brazil and other countries. We have obtained high prestige from our customers for the high quality products, satisfactory after-sales services and competitive price.
3. We will offer free the training for machine’s management ,operation , maintenance to user’s related people.
Please feel free to contact us,we will reply within 24h!
