Cityghost 48W Triac Dimming LED Panel Light 620x620 Germany Standard

Name: Cityghost 48W Triac Dimming LED Panel Light 620x620 Germany Standard
Brand: Cityghost
SKU: 129110193
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

LED Light Source:

4014

Warranty(Years):

Input Voltage(V):

100-265V

Shenzhen Cityghost Lighting Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source 4014

Warranty(Years) 3

Input Voltage(V) 100-265V

Lamp Power(W) 48

Lamp Luminous Flux(lm) 3240

Lamp Luminous Efficiency(lm/w) 90

Color Temperature(CCT) Other, COOL WIHTE, PURE WHITE, WARM WIHTE

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 50000

Lamp Body Material PC

IP Rating IP44

Certification CCC, CE, EMC, GS, LVD, SAA, UL

Place of Origin Guangdong, China

Brand Name Cityghost

Model Number P62036K

Specifications

1. 48W Triac Dimming LED panel light 620x620 2.LED:SMD 4014 3.Three years warranty 4.CE RoHS GS CB SAA approved

1. 36W Triac Dimming LED panel light 620x620

2.LED:SMD 4014

3.Three years warranty

4.CE RoHS approved

5.Long lifespan:>50,000

Specifications

Model	P62036K
Description	Build in Constant currentLED panel light
Dimension	620x 620 x 9.0mm
Lighting source	Lumenmax SMD4014 LED
LED QTY	240pcs
Power consumption	48W(includes driver)
Input voltage (Driver)	180-265VAC/90-130VAC /50-60HZ
Efficiency	≥85%
PF	≥0.90
Input voltage (Lighting)	48-56V DC
Constant current	1120mA
Operation temperature	-40~+50°C
CCT	3000K,4000K, 5000K,6000K
Lighting effecincy	90Lm/W
Luminous	3240lm (±5%)
Ra	Ra ≥ 80
Bean-angle	120 °
Protection grade	IP44
Temperature rising	< 20 °C
Relative humidity	10%-80%RH
Net Weight (includes driver)	3.6KG
Insulation class	CLASS II
Certificate	CE, RoHS, GS, SAA, CB
