240MM LED Round Panel Led Downlight

Name: 240MM LED Round Panel Led Downlight
Brand: Cityghost
SKU: 129105301
Availability: InStock

Shenzhen Cityghost Lighting Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

LED Light Source:

3014

Warranty(Years):

Input Voltage(V):

100-265V

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source 3014

Warranty(Years) 3

Input Voltage(V) 100-265V

Lamp Power(W) 15

Lamp Luminous Flux(lm) 1050

Lamp Luminous Efficiency(lm/w) 67

Color Temperature(CCT) Other, COOL WIHTE, PURE WHITE, WARM WIHTE

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 50000

Lamp Body Material PC

IP Rating IP44

Certification CCC, CE, EMC, LVD, SAA, UL

Place of Origin Guangdong, China

Brand Name Cityghost

Model Number QJL-RP240

Specifications

1.240MM LED Round Panel Led Downlight 2.LED:SMD 3014 3.Three years warranty 4.CE RoHS approved 5.Long lifespan:>50,000

1.240MM LED Round Panel Led Downlight

2.LED:SMD 3014

3.Three years warranty

4.CE RoHS approved

5.Long lifespan:>50,000

Specifications

Model	QJL-RP240
Description	Build in Constant currentLED panel light
Dimension	Φ240*H13mm
Lighting source	Lumenmax SMD3014 LED
LED QTY	150pcs
Power consumption	15W(includes driver)
Input voltage (Driver)	100-265VAC /50-60HZ
Efficiency	≥85%
PF	≥0.90
Input voltage (Lighting)	48-56V DC
Constant current	900mA
Operation temperature	-40~+50°C
CCT	3000K,4000K, 5000K,6000K
Lighting effecincy	67Lm/W
Luminous	1050lm (±5%)
Ra	Ra ≥ 70
Bean-angle	120 °
Protection grade	IP44
Temperature rising	< 20 °C
Relative humidity	10%-80%RH
Insulation class	CLASS II
Certificate	CE, RoHS
