Specifications
API female threaded tubing connector1.Grade: K55
2.Size:from 2 3/8" to 4 1/2"
3.Technics:hot rolling
4.Std ref:API 5CT&5B
API female threaded tubing connector
Features
1.Type:coupling
2.Material:J55, K55, N80-1, N80-Q, L80, C90, P110
3.Size:from 2-3/8" to 4-1/2"
4.Std ref:API 5CT&5B
5.Placement:female
6.Technics:hot rolling
7.Surface treatment: Whole phosphating, or inside phosphating and outside coating
8.Packing: By carton, wooden case, wooden pallet, or by requirements of customers
Technical Parameters
Name |
Thread |
Specifications |
O.D*L(mm) |
Weight(kg) |
Load carring width(mm) |
API 5CT Tubing coupling |
NU |
2-3/8"TBG |
73.02*107.95 |
1.28 |
4.76 |
2-7/8"TBG |
88.90*130.18 |
2.34 |
4.76 |
||
3-1/2"TBG |
107.95*142.88 |
3.71 |
4.76 |
||
4"TBG |
120.65*146.05 |
4.35 |
4.76 |
||
4-1/2"TBG |
132.08*155.58 |
4.89 |
4.76 |
||
EU |
2-3/8"UPTBG |
77.80*123.82 |
1.55 |
3.97 |
|
2-7/8"UPTBG |
93.17*133.35 |
2.4 |
5.56 |
||
3-1/2"UPTBG |
114.30*146.05 |
4.1 |
6.35 |
||
4"UPTBG |
127.00*152.40 |
4.82 |
6.35 |
||
4-1/2"UPTBG |
141.30*158.75 |
6.05 |
6.35 |
Package details
