Specifications
API Swivel Female Shaft Coupling2.Size:from 2-3/8"to 4-1/2"
3.Placement:female
4.Std Rfc:API 5CT & 5B
5.OEM Service
API Swivel Female Shaft Coupling N80
Detailed product Description
Our company manufactures and sells tubing couplings, and we have got API Certificate for tubing couplings. tubing coupling is a connection for oilfield, the features are as follows:
1.Name:API Swivel Female Shaft Coupling
2.Material:J55, K55, N80-1, N80-Q, L80, C90, P110
3.Size:from 2-3/8"to 4-1/2"
4.Surface treatment: Whole phosphating, or inside phosphating and outside coating
5.Packing: By carton, wooden case, wooden pallet, or by requirements of customers
6.Placement:female
7.Std Rfc:API 5CT & 5B
8.OEM Service
Technical Parameters
Name | Size | Type of Thread | O.D*L(mm) | Weight(kg) | Load carring width(mm) | Standard reference |
API Swivel Female Shaft Coupling | 2-3/8"TBG | NU | 73.02*107.95 | 1.28 | 4.76 | API 5CT 5B |
2-3/8"UPTBG | EU | 77.80*123.82 | 1.55 | 3.97 | API 5CT 5B | |
2-7/8"TBG | NU | 88.90*130.18 | 2.34 | 4.76 | API 5CT 5B | |
2-7/8"UPTBG | EU | 93.17*133.35 | 2.4 | 5.56 | API 5CT 5B | |
3-1/2"TBG | NU | 107.95*142.88 | 3.71 | 4.76 | API 5CT 5B | |
3-1/2"UPTBG | EU | 114.30*146.05 | 4.1 | 6.35 | API 5CT 5B | |
4"TBG | NU | 120.65*146.05 | 4.35 | 4.76 | API 5CT 5B | |
4"UPTBG | EU | 127.00*152.40 | 4.82 | 6.35 | API 5CT 5B | |
4-1/2"TBG | NU | 132.08*155.58 | 4.89 | 4.76 | API 5CT 5B | |
4-1/2"UPTBG | EU | 141.30*158.75 | 6.05 | 6.35 | API 5CT 5B |
Package informations
| Specificaiton | Tubing Size OD (inches) | Coupling Size OD (inches) | Length (inches) | Weight per Coupling (kgs ) | Palletized Carton Quantity | Palletized Carton Weight |
| (pieces) | (Kgs) | |||||
API Swivel Female Shaft Coupling (J55,K55, N80,L80,P110) EUE | 1.9 | 2.500 | 3.875 | 0.84 | 2352 | 1976 |
| 2 3/8 | 3.063 | 4.875 | 1.55 | 1152 | 1786 | |
| 2 7/8 | 3.668 | 5.250 | 2.40 | 800 | 1920 | |
| 3 1/2 | 4.500 | 5.750 | 4.10 | 512 | 1229 | |
| 4 | 5.000 | 6.000 | 4.82 | 392 | 1890 | |
| 4 1/2 | 5.563 | 6.250 | 6.05 | 392 | 2372 |
| Specificaiton | Tubing Size OD (inches) | Coupling Size OD (inches) | Length (inches) | Weight per Coupling (kgs ) | Palletized Carton Quantity | Palletized Carton Weight |
| (pieces) | (Kgs) | |||||
API Swivel Female Shaft Coupling (J55,K55,N80,L80,P110)NUE | 1.9 | 2.200 | 3.750 | 0.56 | 3468 | 1943 |
| 2 3/8 | 2.875 | 4.250 | 1.28 | 1690 | 2164 | |
| 2 7/8 | 3.500 | 5.125 | 2.34 | 800 | 1872 | |
| 3 1/2 | 4.250 | 5.625 | 3.71 | 512 | 1900 | |
| 4 | 4.750 | 5.750 | 4.35 | 392 | 1706 | |
| 4 1/2 | 5.200 | 6.125 | 4.89 | 392 | 1917 |
Certificaitons
