You are here:Home>>Aerial Electric Fittings>>
FXB 12 KV High voltage Pin-type long rod suspension & strain composite Insulator
| Item | FXB 12/70 |
Mechanical bending load |
70KN |
Rating voltage |
12KV |
| Height | 350 |
| Arc distance | 180 MM |
| creepage distance | 420 MM |
| Diameter of shed | 90 MM |
Good electrical specification, strong mechanical strength,tensile bending intension of the e poxy glass fiber rod of internalload bearing is double than normal rolled products,8-10 times of high strength porcelain material, can effectively improve the reliable safe operation.
Fine anti-polIution, strong prevent flash accident, and the wet withstand voltage and pollution withstand voltage is 2-2.5 times than the same creepage distance porcelain insulator,and not to cleanup,can safe operate in the serious pollution areas.
This product is applied to high voltage power line service.And have features of good gydrophobicity, anti-ageing,anti-leakage trace and electric erode proof,tensile strength and bending strength,strong mechanical strength,shock resistance good quakeproof and brittle failure proof,light weight,easy to installation, and the in stallation size of top and base are the same size with porcelainpin type, they can exchange to use each other.
| Main techical parameters | |||||||||||||||||||||||||||||||||||||||||||||||
|
1.Packaging:
Export Carton,or as your request.
2.Shipping Methods:
By air or by sea(FOB port:Shanghai/Ningbo),by express (DHL,UPS,TNT,FEDEX).
1. Your inquiry related to our product & price will be replied within 24 hours.
2. Well-trained & experienced staff are to answer all your inquiries.
3. Customized solution & perfect after-sale service.
4. Our advantage:
A.Competitive price B.Good quality
C.Timely delivery D.New model launch weekly
E.Own manufacturing F.Own quality control
1.Manufacturer With Competitive Price And High Quality.
-We are the manufacturer with direct sale price and high quality to help you open the markets which located in Wenzhou City, Zhejiang Province, China. Welcomed to visit our company.
2.OEM/ODM.
-We are the manufacturer with a brilliant team work team work.
3. Usual Payment Term.
-We accept terms of T/T in advance, L/C, Western Union and others. Any question, please ask us!
4. Warranty Time.
-1.5 years. Any problem of the quality is changed by your next order free.
5.Free Sample.
-Yes, we provide small products to check quality for you, just you pay the express fees.
You are here:Home>>Aerial Electric Fittings>>SMICO FXB 12 KV High voltage Pin-type long rod suspension & strain composite Insulator
