Specifications
WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line1.assembling
2.welding
3.straightening
1.Technology of WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
Web height |
200-2500 mm |
Web thickness |
6-30 mm |
Flange width |
200-1000 mm |
Flange thickness |
6-40 mm |
H beam length |
4000-15000 mm |
Working speed |
400-1000mm/min |
Input roller |
12000 mm |
Output roller |
12000 mm |
Power supply |
AC/380 V/60 Hz/3PH |
Welding type |
Transverse fillet welding |
Angle of torch |
45°fine adjustment |
|
|
2. Advantage of WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
tapered degree |
No limit |
|
space needed |
Around 34mx5m |
|
welding mode |
Flat fillet welding |
|
operators |
3 persons easy training, the person can operate |
|
efficiency |
One shift one day, 240T per month for standard parts |
|
welding quality |
Efficient penetration,strong welding seam |
|
benefit |
Good for small workshop,thin plate and not have enough workers. |
|
shipment cost |
1 of 40HQ |
|
3.Application of WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
Cranes manufacture, steel structure manufacture,bridge building,h beam build up,automatic light h beam welding,spot welding machine, steel fabrication
4.Machine seat and support column process of WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
Steel box column processed on CNC machining center, to make sure good fitting and high strength
5.Strict and serious quality testing for WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
There are two moving quality inspectors at each process, and the manager for each shift and monitor the production closely. Inspect and correct the parts after machining before assembling.
6.Factory and Workshop show for WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
7. Package and shipment for WUXI H I Beam 3 in 1 automatic welding Machine h beam welding line
8. Warranty and Service after sales
Warranty time: 12months since machinery installation finished.
Service after sales:
Professional Installation and training at customer spot factory,during time decides by different machine.
Lower price of consumable parts than markets .
Trouble response: 24hours online reply. If broken parts is not comsumable parts or breaks by wrong operation, we can send the broken parts free once confirmed.
Engineer service available overseas.
9.Exhibitons and products
