Card Swiping Intelligent Car Parking Sytem With Voice Prompt for Residential,Office Building,Docks,Jails,School,Hospital,Parks

Card Swiping Intelligent Car Parking System with Voice Prompt for Residential,Office Building,Government Building,Docks,Jails,School,Hospital,Military Bases,Nuclear Power Station,Parks etc.

short range 3-15cm RFID
auto dispense card
voice prompt
for registered and occasional parker

WQ-861 Car parking system for both occasional parker and registered parker

For a occasional parker, when he comes to entry, he himself presses a button to take a proximity card from entry controller, after thatthe entry barriers auotmatcilly opens and he enters, when he exit where a manual-pay-station is installed nearby, he gives his card to the guard, and the guard read the card into a card reader, parking amount will be shown on the computer, then the parker pay cash and then barrier open and he leaves.

For a registered parker, he swipes this registered proximity card onto entry controller, the entry barrier will automatically open and he enters, the same will happen at exit.

Eqippments as belows:
1, Entrance Equipment:
A), Automatic Barrier (straight arm)
B), Vehicle sensor 1 and cable
C), Equipments for RFID
      a, Box for entry
      b, Control board
      c, ID reader
      d, Card machine
      e, Vehicle sensor 2 and cable
      f: Led Graphic Display
     g: Voice prompt (optional)
     h: Villa intercon system (optional)
     i: power

2,  Exit Equipment:
A), Automatic Barrier (straight arm)
B), Vehicle sensor 1 and cable
C), Equipments for RFID
      a, Box for exit
      b, Control board
      c, ID reader
      d: Led Graphic Display
      e: Voice prompt (optional)
      f: Villa intercon system (optional)
     g: power

3), Management center
A), ID card register
B), Management software and software dog
C), Management computer (no quote)
D), Communication shift
E), ID card
F), The main engine of Villa intercon system (optonal)

Details of barriers:
size: 330 x 330 x 1100mm
Arm Material: aluminum alloy
Housing  material: 1.8mm cold-rolled steel plate
Voltage: 220V ± 10, 110 ± 10%
Net weight: 49kg
Motor voltage: 220V
Gross weight: 50kg
Protection grade: IP65
Rail up or down time: 4 to 6 seconds

Transmission Sine Linkage

Boom Type: Straight

Rated Power: 80W

Boom Length: ≤6000mm

Frequency: 50 to 60 Hz

Boom Dimension(W*H): 45*100mm

Working Temperature: -45 to +80 degree centigrade

Boom Weight: 5.5kgs

Operating Humidity: ≤90% RH ( non-condensing)

Operation Lifespan: ≥5 million times

Details of Parking Box:

Material: 1.8mm cold-rolled steel plate

Size: 460*430*1500cm

The system can be achieved by card read and spit-vote in two ways
