Turnstile for access control
Technology specification
| Framework | 304 Grade Stainless Steel |
| Specification | 1400*300*1000(mm) |
| Weight | 80(kg) |
| Arm length | 280(mm) |
| Interface | standard port-RS485 |
| Power voltage | AC110-220 V (10%more or less),50-60HZ |
| Drive voltage | 24V |
| Transit speed | 30—40persons per minute |
| Working Environment | Indoor/Outdoor (with a tent over) |
| Temperature | 25 below degree to 60degree |
| Humidity | ≤90% non-condensing |
Alarming when illegal infiltration or tailing Turnstile for access control system with counting function
Integrating mechanism, electronic with micro-processor as well as diversified technology of identity, wing barrier is a promotion of intelligent tripod turnstile.
Product functions and features
1 With a self-test and alarm function, user-friendly maintenance and use
2 Through the main control on the half-built small-press plate, programmable devices running status
3 Mechanical structure, sensor features dual anti-trap, in the process of telescopic boom reset when you meet resistance, automatically stop or in the default time motor stopped working
4 Sound, light alarm functions, including unlawful entry, trailing alarm
5 Erosion control features, in the absence of gate opening signal is received, the arm automatically locked
6 Telescopic synchronization
7 With automatic reset function, gate opening, after a specified period of time does not pass, the system will automatically cancel the user's current access permissions
8 Power off automatically after the channel open, power-on self-closing
9 Connecting with a variety of reading devices which can be linked to the work of receiving the signal relay switch
10 May be one-directional or bi-directional control personnel access to
11Managing computer directly through the remote control and management
12Counting function can be expanded
13Chassis lengthened, telescopic boom material selection
