Pedestrian Barcode Scanner Flap Turnstile Waist High Turnstile with Wide lane For Disable People

FOB Price

USD $998 - $1,200 / Pair

1 Pair(Min.Order)

Supply Ability 300 Pair / Pairs per Month
Port SHENZHEN/HK
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

WQH

Model Number

WQH-TR04

Product Description

Our Service

Product Description

Function:

1. working method can be set by the buttons on the main panel

2. This model is double wing flap gate, low noise, smaller casing, save space

3. Total new leading technology: Encoder+Brushless Motor

4.Anti-illegal in, anti-intrusion, auto close for reverse direction.

5. Anti-collision, gate closes when no valid signal is given.

6. Gates can be synchronous

7.Auto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.

8. Reset function by photocells,Anti-pinch function by photocells, ( 3 or 5 pairs sensors)

9. Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.

10. One way or two way control

11 Unit can be controlled and administered by remote control

Extensible functions:

1. LED counter display

2. Casing and gate size can be lengthened

3.Lgic judgment by photocells (7pair or 9 pairs)

4.Speech reminder

5.normal close or normal open adjustable

6. Light, sound alarm

-----------------------------------------Technical Parameters----------------------------------------

Name	Flap Barrier/Flap Turnstile	Transmission	Sine Linkage
Model No.	WQH-TY04	Frenquency	50-60Hz
Housing Size	420x330x980mm	Control type	IC/ID/Barcode control accepted
Housing Material	304 grade stainless steel optional	Max Channel Width	600mm
Passing speed	30 person/min	Logic voltage	24v
Working voltage	AC220V±10V, 50HZ	Direction	Single or Bi-directional
Motor voltage	220V	Operating humidity	≤90% non-condensing
Rated Power	80w	Operation life	≥5 million times
Working temperature	-45°C--+80°C	Net Weight	60kg
Communication Interface	RS485/RS232	Gross Weight	65kg

------------------------------------------Our Project Cases-------------------------------------------

Order Procedure

1: Customer Inquiry	2:Quotes
3:To give orders	4:The next production orders
5:Business approval	6: Production Notification issued
7: Production starts	8:Inspection before shippment
9:The charter provides warehouse:	10:loading
11:Commissioned by the declaration	12:To obtain shipping documents
13:To prepare the relevant documents	14:Making the export contract, export commercial invoice, packing list and other documents
