JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane

JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-1
JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-2
JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-3
JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-4
JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-5
JD-180 Digital Angle Sensor Used for Kato/tadano Truck Crane photo-6
US$ 200 - 295 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WTAU
Model Number:
JD180-L ; JD180-R
Usage:
Other, It can be installed on crane boom,angle measurement.
Payment & Shipping
Payment Methods:
Port of Shipment:
Yichang
Delivery Detail:
Delivery time depends on order quantity.
Brand Name WTAU
Model Number JD180-L ; JD180-R
Usage Other, It can be installed on crane boom,angle measurement.
Theory Other, JD - 180 type Angle Meter is composed of potentiometer and pendulum
Output Other, DC3-6.9V

Specifications



digital angle measurement
1.Stable system
2.Easy to operate
3.Long service life
4.1 year quality gurantee



digital angle measurement used for mobile crane

1.Discription



JD - 180 type Angle Meter is composed of potentiometer and pendulum; It can be installed on crane boom. The boom on point of view is measured by the heavy hammer driving potentiometer rotating, then output corresponding voltage;

JD-180 digital angle sensor used for Kato/tadano truck craneJD-180 digital angle sensor used for Kato/tadano truck crane



2.Main Technical Data for Angle Meter











Model: JD180-L (Left Mounted) JD180-R (Right Mounted)







Components:conductive plastic potentiometer (CPP)







Measuring Range: -10°~+110°







Rated Output: DC3~6.9V/0 ~ 90°







Working Voltage: DC15V







Linearity:0.1,0.5,1%







Impact Resistance: 20g15~20ms







Water Resistance: Waterproof







Working Humidity: 10~95%







Working Temperature: -20~+60°C



 JD-180 digital angle sensor used for Kato/tadano truck craneJD-180 digital angle sensor used for Kato/tadano truck crane

Installation Picture Show

JD-180 digital angle sensor used for Kato/tadano truck crane

Welcome to visit us!



Yichang WTAU Electronic Equipment Co. Ltd is a national high-tech enterprise which located in the “Hydropower capital”— Yichang. WTAU is committed to researching , developing and producing safety devices for crane cranes , automatic monitoring control systems , etc. WTAU puts the principle “make sure the lifting equipments are operated safely and reliably” as our duty and takes the high-tech as the core. WTAU has awarded many patents and major achievements of science and technology. The Torque Limiter, Weight Limiter, Anemometer ,etc. which are researched independently  are widely used in electrical, chemical, steel, metallurgy, construction, ports, shipping and other industries.

 JD-180 digital angle sensor used for Kato/tadano truck craneJD-180 digital angle sensor used for Kato/tadano truck craneJD-180 digital angle sensor used for Kato/tadano truck crane
