Triple Output Power Supply for Digital Audio Player

Name: Triple Output Power Supply for Digital Audio Player
Brand: Kaihui
SKU: 129047727
Availability: InStock

Guangzhou Kaihui Electronics Co., Ltd.

US$ 3.5 - 30 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Kaihui

Model Number:

K802

Payment & Shipping

Payment Methods:

Port of Shipment:

GuangZhou port ; shenzhen port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Kaihui

Model Number K802

Input Voltage 85-132V AC , 170-264VAC

Output Voltage -15V-24V

Output Power 30W

Output Frequency 47-63 HZ

Output Current 0.3A-2A

Specifications

Buil-in EMI filter, low ripple noise
Built-in remote ON/OFF control
Protections: shortcircuit/ Over load

High efficiency, low temperature
Product: Light/ Thin/ Short/ Small
Built-in EMI filter, low ripple noise
100% full load burn-in test
Protections: Short circuit/ Over load
Input voltage range -----------85~132V AC,170~264V DC
Input frequency -----------47~63Hz
Inrush current-------- Cold start 15A/115V 30A/230V
Over load protection ------105%~150%(rated load),Auto-recovery
Withstand voltage---------- Input-Output: AC1.5KVACV,1min; Input-Ground:AC1.5KVACV,1min;
Working temperature ------ -10~+50℃@100%, 60℃@60%load
Safety standards -----------MeetGB4943
Weight ---------------0.35KG
Code	Item No.	Output	Tol.		R&N		Effi.
0207	K02-U30T5 ± 12	+5V,2A +12V,1A -12V,0.5A		±2%		100 mV		74%
0208	K02-U30T5 ± 15	+5V,2A +15V,1A +15V,0.5A		± 2%		100mV		74%
0209	K02-U30T5+12+24	+5V,2A +12V,1A +24V,0.3A		± 2%		100mV		74%
