Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A)

Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-1
Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-2
Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-3
Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-4
Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-5
Printing-desktop uv Liquid Laminating Machine for Surface of the Pictures ,photo and Printings (LM-A) photo-6
US$ 1,000 - 2,560 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Commodity
Automatic Grade:
Semi-Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Commodity
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage AC220v/50hz
Power 4.5kw
Packaging Type Other, paper
Packaging Material Wood
Place of Origin Guangdong, China
Brand Name HY
Model Number LM-A
Dimension(L*W*H) 1015*935*500mm
Weight 158kg
Certification CE
After-sales Service Provided Overseas service center available

Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)




 Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)











Introduce:



1.Laminating film for photo ,paper,pringting etc.



2.Automatic replenishment glue ,no-clean



3.Easy to operate,low cost



4.High speed,shorten the drying time



5.Occupy small space and easy transporation









parameter







Laminating Machine(LM-A)

Specification

12 inches

18 inches

24 inches

Working width

340mm

480mm

620mm

Working thickness

5mm

5mm

5mm

Speed

10m/min

10m/min

10m/min

Dry way

UV

UV

UV

Power supply

AC220V/50HZ

AC220V/50HZ

AC220V/50HZ

Max rate of power

4.5KW

4.5KW

4.5KW

Machine dimension

995*732*495mm

860*935*495mm

1012*935*495mm

N/G

72.2KG/97.5KG

90.5KG/112.5KG

118KG/146KG

Packing size

775*770*710mm

897*778*714mm

1050*815*705mm





Cost analysis:





he thickness of the uv liquid can be adjusted , normally it’s 3-5g/m2 and it can be diluted by alcohol.One kilogram of uv liquid can coat an area of 300 m2 pictures,which means that the actual cost is 0.3 RMB /m2 to 0.5 RMB/m2, If cold lamination, the prime cost is 7.5RMB/m2,the prime cost for inkjet printer machine is 3-5RMB/m2,hence buying a uv coating machine is a machine that earns money.



Showroom and workshop







 Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)



 Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)



 Certification

 Printing-desktop uv liquid laminating machine for surface of the pictures ,photo and printings (LM-A)
