Agricultural machinery farming tractor DY620 mini tractor for sale

Specifications

1.extreme compact design;
2.multifunctional with hundreds of attachments;
3.small turning radius
escopic boom

Agricultural machinery farming tractor DY620 mini tractor for sale



Our DY620 is a multifunctional machine.  It adopts european standard quick coupling system, which enable the customer use hundreds of different attachments.



It is hydrostatic four wheel drive machine, has four independent hydraulic wheel motor.



Compared with other same size machines, its telescopic boom which can reach 2750mm widely increase its working scope.



Special articulated structure with seat in front position helps it gain a much smaller turning radius than other same size machine.



It's control is very simple by levels and buttons. The pressure testing connector on chassis, and all relative warning lights and sounds also greatly simplified the maintainence.



Detailed specifications as below. Welcome to visit our factory to test it yourself, we are confident that you'll fall in love with it!



Model	DY620
Max. length	2195 mm
Max. width	980 mm
Max. height	2100 mm
Bucket capacity	300L
Rated loading capacity	500kg
Max. loading capacity	800kg
Min. turning diameter	1980mm
Turning angle	400
Speed	10 km/h
Weight	1100 kg
Standard tire	23X8.5-12
Tire pressure	2.8 bar
Oil tank capacity	35L
Pressure	190bar
Oil model(mineral oil)	L-HL46
Engine brand	Perkins 403D-07
Number of cylinder	4
Cooling system	Water cooling
Rated power	12.5Kw
Rotation speed	2800 r/min
Fuel tank capacity	18L
Battery capacity	55Ah
Voltage	12v
