china cheap hot sale wheel loader TY18 used in farm, gardening and construction sites :
The specifications is as below:
Model |
TY18 |
|
Engine Details |
Engine model |
Yunnei 4102 |
|
Engine power |
60kw, |
|
Rated Speed |
2400/r/min |
|
Engine cooling way |
Water cooling |
|
Fuel Consumption ratio |
230g/kw.h (standard working condition) |
|
Engine type |
In-line arrangement,4 cycle diesel Engine |
Bucket |
Bucket Capacity |
0.8 m3 |
|
Bucket width |
1700mm |
|
Bucket type |
Heavy-duty bolt on teeth |
Overall Dimensions |
Overall Length |
4650mm |
|
Overall Height |
2720mm |
|
Overall Width |
1870mm |
Brake System |
Service Brake |
Four Wheel disk brake |
|
Parking Brake |
Hand operated |
Max. lifting Height |
3450mm |
|
Rated Load |
1800kg including attachment |
|
Transmission System |
Hydraulic converter + drive shaft + axles |
|
Tyre Model |
17.5-16 |
|
Wheelbase |
2400mm |
|
Track |
1345mm |
|
Min Turning Radius: |
4950mm |
|
Weight |
3800kgs |
|
System Pressure |
19Mpa |
|
Hydraulic output |
96L/min |
|
Max. Height to the Pin |
4200 mm |
|
Braking Type |
Air braking |
|
Axle |
With hub reducer |
|
Hydraulic Oil Model |
L-HL46 |
|
Battery |
105Ah * 2, 24V |
|
You are warmly welcomed to visit our factory.
