china front end wheel loader for sale with cheap price:
front wheel loader
1.We have been making such kind of loader for 14 years, every single part of the loader has been tested by market, thus it is a reliable mature product.
2.Standard quick hitch system enable it can use many different kind of attachments.
3.Special treatment of vibration and noise makes it stand out from other loaders.
4.Optional rear hydraulic output makes it a combination of loader and tractor.
5.With the support of an experienced engineering team, we can realize customers’ special requirements
Model | TY18 | |
Engine Details | Engine model | Yunnei 4102 |
| Engine power | 60kw |
| Rated Speed | 2400/r/min |
| Engine cooling way | Water cooling |
| Fuel Consumption ratio | 230g/kw.h (standard working condition) |
| Engine type | In-line arrangement,4 cycle diesel Engine |
Bucket | Bucket Capacity | 0.8 m3 |
| Bucket width | 1700mm |
| Bucket type | Heavy-duty bolt on teeth |
Overall Dimensions | Overall Length | 4650mm |
| Overall Height | 2720mm |
| Overall Width | 1870mm |
Brake System | Service Brake | Four Wheel disk brake |
| Parking Brake | Hand operated |
Max. lifting Height | 3450mm | |
Rated Load | 1800kg including attachment | |
Transmission System | Hydraulic converter + drive shaft + axles | |
Tyre Model | 17.5-16 | |
Wheelbase | 2400mm | |
Track | 1345mm | |
Min Turning Radius: | 4950mm | |
Weight | 3800kgs | |
System Pressure | 19Mpa | |
Hydraulic output | 96L/min | |
Max. Height to the Pin | 4200 mm | |
Braking Type | Air braking | |
Axle | With hub reducer | |
Hydraulic Oil Model | L-HL46 | |
Battery | 105Ah * 2, 24V | |
Standard color is orange, but just with a reference color code, we can make it ideal appearance as you excepted.
Our brand name is "TAIAN", but OEM is acceptable and welcomed.
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
