front end loader, hydraulic pilot 1.8 ton wheel loader price list:
front end wheel loader
1.Different engines available, chinese or oversea brands.
2.Standard quick hitch system
3.Wide view cabin with interior, modern control board and suspension seat makes the operation comfortable and enjoyable
4.Low vibration and noise
5.Different type of transmission system available
6.Rear hydraulic output optional
Model |
TY18 |
|
Engine Details |
Engine model |
Yunnei 4102 |
|
Engine power |
60kw |
|
Rated Speed |
2400/r/min |
|
Engine cooling way |
Water cooling |
|
Fuel Consumption ratio |
230g/kw.h (standard working condition) |
|
Engine type |
In-line arrangement,4 cycle diesel Engine |
Bucket |
Bucket Capacity |
0.8 m3 |
|
Bucket width |
1700mm |
|
Bucket type |
Heavy-duty bolt on teeth |
Overall Dimensions |
Overall Length |
4650mm |
|
Overall Height |
2720mm |
|
Overall Width |
1870mm |
Brake System |
Service Brake |
Four Wheel disk brake |
|
Parking Brake |
Hand operated |
Max. lifting Height |
3450mm |
|
Rated Load |
1800kg including attachment |
|
Transmission System |
Hydraulic converter + drive shaft + axles |
|
Tyre Model |
17.5-16 |
|
Wheelbase |
2400mm |
|
Track |
1345mm |
|
Min Turning Radius: |
4950mm |
|
Weight |
3800kgs |
|
System Pressure |
19Mpa |
|
Hydraulic output |
96L/min |
|
Max. Height to the Pin |
4200 mm |
|
Braking Type |
Air braking |
|
Axle |
With hub reducer |
|
Hydraulic Oil Model |
L-HL46 |
|
Battery |
105Ah * 2, 24V |
|
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
