80HP front end loader as agriculture machinery
Our company was established in 2001, and since then we have been focus on all kinds of loaders development, good innovation ability enable us to keep developing and stand out from other similar products. We have been awarded with 4 patents till now, variable products can meet customers different requirements.
front end loader
Front and optional rear hydraulic output together with the quick coupling system makes it the transformers of machinery. Our loaders can be used wherever needs a machine, farming, landscaping, construction, estate and property maintenance, etc.
front end loader
1.Different engines available, chinese or oversea brands.
2.Standard quick hitch system
3.Wide view cabin with interior, modern control board and suspension seat makes the operation comfortable and enjoyable
4.Low vibration and noise
5.Different type of transmission system available
6.Rear hydraulic output optional
Model |
TL2500 |
|
Engine Details |
Engine model |
YUNNEI 4102GB |
Engine power |
58KW (78.88H.P.) |
|
Rated Speed |
2400 r/p.min |
|
Engine cooling way |
Water cooling |
|
Fuel Consumption ratio |
180g/kw.h (standard working condition) |
|
Engine type |
In-line arrangement,4 cycle diesel Engine |
|
Overall Dimensions |
Overall Length |
4500mm |
Overall Height: |
2720mm |
|
Overall Width |
1870mm |
|
Brake System |
Service Brake |
Four Wheel disk brake |
Parking Brake |
Hand operated |
|
Braking Type |
Air braking |
|
Axle |
With hub reducer |
|
Max. lifting Height |
4500mm |
|
Rated Load |
2500kg including attachment |
|
Transmission System |
Hydraulic converter + drive shaft + axles |
|
Tyre |
16/70-20, 12ply |
|
Wheelbase |
2430mm |
|
Min Turning Radius |
5600mm |
|
Track |
1470mm |
|
Weight |
4900kg(without bucket) |
|
System Pressure |
20Mpa |
|
Hydraulic output: |
96L/min |
|
Max. Height to the Pin |
4200 mm |
|
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in our machine, Please contact with: Steven N.
